    Rhino MSCAM-BI28 Vehicle Reverse Infrared Bullet MSCAM-BI28

    Rhino MSCAM-BI28 Vehicle Reverse Infrared Bullet Camera with Bracket

    MSCAM-BI28
    In Stock - Ready to Ship
    $ 41.99
    inc-GST

    or 4 interest-free payments of $10.50 with

    • Weather resistant infrared bullet camera
    • 420TVL resolution
    • 648(H) x 488(V) effective pixels
    • 120° field of view
    • Vandal resistant
    • 12V ~ 24V power input



    RhinoCO Vehicle Reverse Infrared Bullet Camera with Bracket



    MSCAM-BI28



    The RHINO™ MSCAM Series of professional vehicle reverse cameras comprises intuitively designed cameras built for demanding weather environments. Each model features an innovative bracket for optimal installation and some feature infrared LEDs for night vision performance. The series is ideal for everyday driving and also large fleets of trucks and buses.





    Product Features:



    • Weather resistant infrared bullet camera with mounting bracket

    • 420TVL resolution

    • 648(H) x 488(V) effective pixels

    • 120° field of view

    • Vandal resistant

    • 12V ~ 24V power input



    Specifications:



    General

    Camera StyleWeather Resistant Bullet
    Image Sensor1/4 CMOS
    Effective Pixels648 (H) x 488 (V)
    MirroredYes

    Camera

    Lens2.8mm
    Minimum Illumination0.5 Lux
    Maximum Infrared Range5m

    Video

    Resolution420TVL
    Video Output1 channel RCA (1.0Vp-p, 75 ohms)

    Environment

    Ingress ProtectionIP67
    Vandal ResistantYes
    Power Input12V-14V
    Power Consumption< 100mA
    Operating Environment-10° to 50°C / RH95% (max)
    Dimensions28 x 30 x 22mm
    Warranty (Years)1



    MSCAM%20Vehicle%20Camera%20Series%20-%20Product%20Brochure%20(PDF)-1.jpgMSCAM%20Vehicle%20Camera%20Series%20-%20Product%20Brochure%20(PDF)-2.jpg

    Dimensions
    28 x 30 x 22mm
    Power input
    12V-24V
    Ingress Protection
    IP67
    Operating Environment
    -10° to 50°C / RH95% (max)
    Power Consumption
    < 100mA
    Video Output
    1 channel RCA (1.0Vp-p, 75 ohm)
    Resolution
    420TVL
    Vandal Resistant
    Yes
    Camera Style
    Weather Resistant Bullet
    Effective Pixels
    648 (H) x 488 (V)
    Image Sensor
    1/4 CMOS
    Lens
    2.8mm
    Maximum Infrared Range
    5m
    Minimum Illumination
    0.5 Lux
    Mirrored
    Yes
