LFL-G480-C2 • 480 W Adjustable LED Flood Light
≈ 81 600 lm • 170 lm/W • 60° × 100° beam • 5000 K • IP67 / IK10 • DALI & DMX
Need competition-grade punch for ovals, logistics yards or high-mast wharves? The ENSA™ LFL-G2 480 W unleashes a blistering 81 600 lumens through an asymmetric 60° × 100° optic. Four independent LED panels fine-tune spill light, while the DALI-2 / DMX-512 driver keeps power factor > 0.95 on any 100 – 277 VAC supply. Built around a sealed IP67 / IK10 aluminium chassis and rated 100 000 h L70, it’s the LED powerhouse that ends HID re-lamp budgets for good.
Key Advantages
- ≈ 170 lm/W efficacy – swaps straight in for 1 kW metal-halide while slashing kWh 55 %.
- 60° × 100° forward-throw lens – drives lux deep into fields, suppresses neighbour glare.
- Quad 90° rotatable modules + 180° U-bracket – aim hotspots exactly where play happens.
- DALI-2 or DMX-512 – fade pre-game, fire up light shows, integrate daylight harvesting.
- IP67 / IK10 – rains, dust, hail balls, wayward footballs; nothing fazes the die-cast body.
- 100 000 h LED life + field-replaceable driver for decade-long total-cost wins.
- 3-year warranty (extendable) • RCM, CE & RoHS compliant.
Typical Applications & Pole Guides
Football & Rugby Ovals – 25 m masts. Six lights around the boundary average ≈ 120 lx (AS 2560 Class II) with < 1 : 2 uniformity.
Tennis / Pickleball Centres – 10 m poles. Two fixtures per court deliver 350 lx centre, 250 lx baseline, perfect for HD streaming.
Container Terminals – 30 m high-mast. Eight units on a ring-head flood 120 × 120 m pads at 45 lx; DMX scenes dim to 20 % off-shift.
Airport Aprons – 20 m poles. Four fixtures bathe a 90 × 90 m stand at 30 lx for safe refuelling & turnaround.
Mining ROM Pads – 15 m mobile towers. Twin LFL-G480-C2s give 100 lx task lighting, withstand -20 °C to +55 °C and vibration.
Need a Dialux or AGi 32 plot? Email your pole layout – fast 24 h turnaround.
Single-Fixture Centre-Beam Lux*
| Distance |
10 m |
20 m |
30 m |
50 m |
70 m |
100 m |
150 m |
| Lux |
≈ 525 lx |
≈ 131 lx |
≈ 58 lx |
≈ 21 lx |
≈ 11 lx |
≈ 5 lx |
≈ 2.3 lx |
*Based on peak candela ≈ 52 600 cd (E = I / d²). Always verify with lighting software.
Multiple-Fixture Lux Estimator
Centre-zone values with beams overlapping about 20 %:
| Distance |
1 × 480 W |
2 × 480 W (12 m apart) |
3 × 480 W (18 m apart) |
4 × 480 W (24 m apart) |
| 10 m |
≈ 525 lx |
≈ 900 lx |
≈ 1250 lx |
≈ 1550 lx |
| 20 m |
≈ 131 lx |
≈ 225 lx |
≈ 310 lx |
≈ 380 lx |
| 30 m |
≈ 58 lx |
≈ 100 lx |
≈ 140 lx |
≈ 175 lx |
| 50 m |
≈ 21 lx |
≈ 37 lx |
≈ 52 lx |
≈ 65 lx |
| 70 m |
≈ 11 lx |
≈ 19 lx |
≈ 27 lx |
≈ 34 lx |
Aim for < 1 : 1.8 uniformity; dial-in pan/tilt onsite.
Lux in Plain English
• < 10 lx – security patrols & monochrome CCTV.
• 20 – 50 lx – casual sport, general parking, loading docks.
• 100 lx + – competitive play, aircraft stands, precision assembly.
Quick Specs
| Optical Output |
≈ 81 600 lm • 170 lm/W |
| Power / Input |
480 W @ 100–277 VAC 50/60 Hz • PF > 0.95 |
| Beam / Lens |
60° × 100° PC asymmetric |
| CCT / CRI |
5000 K • > 80 Ra |
| Controls |
DALI-2 / DMX-512 dimming |
| Housing |
IP67 / IK10 aluminium, PC lens |
| Adjustments |
4 × 90° panel tilt • 180° bracket |
| Size / Weight |
≈ 920 × 230 × 75 mm • ≈ 18 kg |
| Life & Warranty |
100 000 h L70 • 3 yr std / ext opt |
Cheat-Sheet Mounting Scenarios
| Scenario |
Setup & Aiming |
Coverage & Avg Lux |
| 10 m pole |
1 × 480 W @ 18° tilt |
50 × 35 m court • ~90 lx |
| 15 m pole |
2 × back-to-back |
50 × 70 m yard • ~60 lx |
| 20 m mast |
3 × fan-aimed |
75 × 75 m pad • ~45 lx |
| 25 m ring-head |
8 × even spacing |
Ø 170 m oval • ~30 lx |
| Wall 12 m |
1 × 480 W @ 10° |
60 m lane • ~20 lx |
-1.jpg)
-2.jpg)
Light it once — win for years.
Swap legacy metal-halide for the LFL-G480-C2 and score instant-on 5000 K clarity, DALI/DMX smarts and 60 % energy savings. Add to cart & elevate your field.
