Permaconn PM45-4G 4G PM45 Alarm Communicator
    Permaconn PM45-4G 4G PM45 Alarm CommunicatorPM45-4G
    Permaconn PM45-4G 4G PM45 Alarm Communicator
    Permaconn PM45-4G 4G PM45 Alarm CommunicatorPM45-4G

    Permaconn PM45-4G 4G PM45 Alarm Communicator

    PM45-4G
    In Stock - Ready to Ship
    $ 217.30
    inc-GST
    • Remote “over-the-air” alarm panel
    • Dual SIM + IP alarm communicator
    • Plug & Play solution
    • Interfaces with any Contact
    • ID alarm pane
    • 3 input + 3 output, function control
    • Communicator automatically switches between 4G and 3G networks
    • Low current draw, easily powered from alarm pane

    Various Payment Types at Checkout.

    All Payment Options are available at Checkout: Visa/MC/Amex, Zip, Afterpay, Paypal and Bank Dep



    Permaconn 4G PM45 Alarm Communicator



    PM45-4G



    The PM45-4G is a versatile alarm communicator that reports on 4G, GPRS and IP to the Central Station. This unit can interface with a range of alarm panels using Contact ID. Primary alarm path is IP, followed by 4G/GPRS in the event of a wired ethernet failure. If no IP connection exists the communicators will report on GPRS or 4G only.



    Product Features:

    • Small size - Fits inside alarm panel enclosure and suitable for ATM & M2M applications

    • Secure VPN within Optus & Telstra networks - Dedicated for Permaconn events only

    • AES128 encryption for alarm data - Secure transmissions over the public internet

    • High speed RS232 Interface - Future development

    • Various diagnostic LEDs - Easy installation

    • Activate, commission and diagnose using Atlas - Seamless installation process

    • Three (3) dedicated paths of communication - Uptime in excess of 99.9%

    • Internal watchdog reset function - No unnecessary service call-outs

    • Monitors & reports dialler interface lead status - Panel dialler to Permaconn interface secure

    • AS/NZ2201.5:2008 compliance



    Dimensions
    110mm (h) x 25mm (d) x 80mm (w)
    Operating Environment
    0°- 50°C @15% to 85% humidity (non-condensing)
    Weight
    120g
    Power
    8–15V DC. Terminal (must power from appoved supply)
    Housing Material
    ABS plastic - Green
    Power Consumption
    Standby: 0.08A @13.8V DC / Transmitting: 0.19A @13.8V DC
    Antenna
    Triple band 3G & Triple band 4G
    Approvals
    EN 55022:2006/A1:2007, AS/CA S042.1-2011, AS/CA S042.4-2011 AS/NZS 60950.1-2011, AES2201.5:2008, EN 62311:2008, EN 301489-1 EN 301 489-24, EN 301 908-1, EN60950-1
    Auxiliary Input
    3 x 24Hr input - state change detected every second. / EOL 3.3K
    Auxiliary Output
    3 x Open Collector output @ 50mA (max) / Function control using Atlas web portal and/or 'Pocket Secure’
    Communication Protocol
    Ethernet (10/100BASE-T)
    Data Security
    AES Encryption
    Modem
    Quectel EC21
    Network Protocol
    DHCP or Static IP
    Serial Port
    High Speed RS232 interface
    Static IP Network Configuration
    Ethernet interface using ‘IpSetup’ program / Atlas web portal using mobile connection
    Supported Modulation
    BELL-103, ITU-V21/V22/V22B
