WT5-UPBAC52
Ubiquiti Networks launches the latest generation of airMAX® CPE (Customer Premises Equipment), the PowerBeam® 5AC Gen 2, with dedicated Wi-Fi management. The PowerBeam 5AC Gen 2 directs RF energy in a tighter beamwidth. With the focus in one direction, the PowerBeam 5AC Gen 2 blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Ubiquiti’s InnerFeed® technology integrates the radio into the feed horn of an antenna, so there is no need for a cable. This improves performance because it eliminates cable losses. Featuring high performance and innovative design, the PowerBeam 5AC Gen 2 is versatile and cost‑effective to deploy.
Incorporating a dish reflector design with proprietary technology, the WT5-UPBAC52 is ideal for CPE deployments requiring maximum performance. Its excellent beam directive provides excellent performance in high-noise environments.
• Built-in mechanical ±20° up/down tilt
• Easy removal with a detachable antenna feed
• Extensive transmission range, exceeding 25km in ideal conditions
• Breakthrough throughput supports up to 450+ Mbps
• Operates with a gain measuring 25dBi
• Frequency range reaching 5Ghz
• Galvanised steel dish reflector for corrosion resistance
• Includes protective radome for further weather protection
• Configure via smartphone over WiFi
| Channel Sizes | PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz |
| Dimensions | 420 x 420 x 230mm |
| Enclosure | Outdoor UV Stabilized Plastic |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Gain | 25 dBi |
| LED | Power, Ethernet, Signal strength |
| Management Radio | 2412-2472Mhz |
| Max. Power Consumption | 8.5W |
| Max. VSWR | 1.5:1 |
| Memory | 64MB |
| Mounting | Pole-Mount (Kit Included) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Operating Frequency | Worldwide: 5150 - 5875 MHz |
| Operating Humidity | 5 to 95% Noncondensing |
| Operating Temperature | -40 to 70° C |
| Polarization | Dual Linear |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Processor Specs | MIPS 74Kc |
| RoHS Compliance | Yes |
| Salt Fog Test | IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 |
| Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
| Supported Voltage Range | 20 to 26VDC |
| Temperature Shock Test | IEC 68-2-14 |
| UV Test | IEC 68-2-5 at 40° C, Equivalent: ETS 300 019-1-4 |
| Vibration Test | IEC 68-2-6 |
| Weight | 2.22kg |
| Wind Loading | 380 N @ 200 km/h |
| Wind Survivability | 200 km/h |
| Wind-Driven Rain Test | ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5 |
| Wireless Approvals | FCC, IC, CE |
| Warranty (Years) | 2 |
