VIP Vision Ultra HD Commercial Grade Network NVD-A9
VIP Vision Ultra HD Commercial Grade Network NVD-A9

VIP Vision Ultra HD Commercial Grade Network Video Decoder (9 x HDMI Out) - NVD-A9

NVD-A9
In Stock - Ready to Ship
$ 5,088.00
inc-GST
  • Roaming decoder displays all video feeds on network
  • Video wall splicing for up to 36 displays per monitor
  • Split screen control with zoom/merge/roam/overlay
  • Switch between standard & high definition streams
  • Decode up to 12CH 4K, 48CH 1080p or 144CH D1
  • Support for audio, alarm, bi-directional talk, RS232, RS485
  • Fisheye dewarp & multi-video split display
  • Manage via web browser or VIP Vision™ SmartPSS



NVD-A9 IP Video Decoder

9-Channel HDMI Video Wall Controller | Network IP Stream Decoder

Effortlessly Control Multi-Screen Video Walls

The NVD-A9 is a professional-grade IP video decoder designed for creating dynamic video wall displays using up to 9 HDMI monitors. This decoder connects directly to your surveillance network, allowing you to stream and display real-time footage from IP cameras, NVRs, or HDMI input sources—all without the need for a PC.

Whether used in control rooms, commercial premises, or public monitoring stations, the NVD-A9 delivers a flexible and reliable solution for surveillance visibility and coordination. With full remote configuration via SmartPSS or web interface, operators can quickly change layouts, camera feeds, or sources on demand.

Key Features:

  • Supports up to 9 simultaneous HDMI outputs for video wall display
  • Streams live footage from IP cameras or network recorders (NVRs)
  • Accepts direct HDMI video input sources for flexible integration
  • Configurable screen layout modes for different monitoring needs
  • Remote management via SmartPSS or web-based interface
  • ONVIF and Dahua-compatible IP stream decoding
  • Perfect for security control centers, public surveillance, or retail monitoring

Specifications:

  • Video Outputs: 9 x HDMI 2.0 (up to 3840x2160 resolution)
  • Decoding Capability: Up to 36 channels of 1080p or 16 channels of 4K streams
  • Network Protocols: TCP/IP, HTTP, RTSP, RTP, UDP, Multicast
  • Video Standards: H.265 / H.264 decoding
  • Audio: Supports audio decoding with HDMI output
  • Control: Via SmartPSS, web GUI, or RS232
  • Compatibility: ONVIF-compliant, Dahua ecosystem ready
  • Power Supply: 12VDC / PoE supported
  • Mounting: Rack-mountable form factor
  • Dimensions: Standard 1U chassis
  • Warranty: 3 Years

Applications:

  • Security operation centers and monitoring rooms
  • Retail store chains and shopping malls
  • Transportation hubs and public safety agencies
  • Corporate buildings with centralized surveillance systems
