VIP Vision Professional AI Series 4.0MP PTZ Compact Dome 25x Zoom - VSIPPTZ-4IRC-I
- Stream up to 4.0MP (2560x1440) at 50fps
- Up to 25 x Optical zoom.
- 5 mm – 125 mm motorised varifocal lens with 3.0° ~ 51.9° viewing
- H.265 encoding for efficient storage & streaming
- Built-in microphone and microSD slot for edge recording
- 3D digital noise reduction & true WDR (120dB)
- Tripwire, Intrusion, Motion detection and more
- Power via 12VDC or Power over Ethernet (802.3at)
- IP66 weather resistance
- Includes 24VAC/3A PSU.
VIP Vision Professional AI Series 4.0 MP PTZ Compact Dome
VSIPPTZ-4IRC-I
This network PTZ dome offers versatile surveillance and affordability without skipping the highlights of the Pro AI Series. Ensure all areas are covered with up to 25x optical zoom. Experience impressive AI with real-time face detection and AI Perimeter Protection technology, providing meaningful video event notifications in real time.
Camera Features:
• Stream up to 4.0MP (2560x1440) at 50fps
• 5 mm – 125 mm motorised varifocal lens with 3.0° ~ 51.9° viewing
• H.265 encoding for efficient storage & streaming
• Built-in microphone and microSD slot for edge recording
• 3D digital noise reduction & true WDR (120dB)
• Tripwire, Intrusion, Motion detection and more
• Power via 12VDC or Power over Ethernet (802.3at)
• IP66 weather resistance
Includes 24VAC/3A PSU.
- Dimensions
- Ø168.0 mm × 171.1 mm
- Ethernet
- RJ-45 (10/100Base-T)
- Housing
- Plastic
- Net Weight
- 2.5 kg
- Operating Conditions
- -40°C ~ +65°C
- Power Supply
- 12 VDC (±30%); PoE (802.3af); ePoE
- Ingress Protection
- IP66
- Vandal Resistance
- N/A
- Bit Rate
- H.264: 2816 kbps–13056 kbps H.265: 1024 kbps–7936 kbps
- Frame Rate (Main)
- 4MP (1–25fps)
- Frame Rate (Sub)
- D1 (1-25fps)
- Frame Rate (Third)
- 720p (1 ~ 25fps)
- Max. User Access
- 20 Users
- Power Consumption
- Video Compression
- H.265/H.264B/H.264M/H.264H/MJPEG/H.265+/H.264+
- Resolution
- 4.0MP (2560 x 1440) to CIF (352 x 288)
- Series
- Professional AI Series
- Focus
- 0.5 m–5 m Min. Focus Distance
- Interoperability
- ONVIF / CGI / SDK / P2P
- Effective Pixels
- 2560 (H) × 1440 (V)
- Image Sensor
- 1/2.8" CMOS
- RS485
- N/A
- Alarm Interface
- 1 channel in: 5 mA 3-5 VDC / 1 channel out: 300 mA 12 VDC
- Camera Type
- PTZ Dome
- Max. Resolution
- 4.0 Megapixel
- Field of View
- 51.9° ~ 3.0° (25x Optical Zoom)
- Lighting Compensation
- BLC / HLC / WDR (120dB)
- Pan / Tilt Range
- Pan: 51.9°–3.0° Tilt: 39.7°–2.2°
- Day/Night
- Auto (ICR) / Color / B&W
- Detect (25px/m)
- 2500 m
- Gain Control
- Auto / Manual
- Identify (250px/m)
- 250 m
- Lens Type
- Motorised Varifocal
- Noise Reduction
- 2D / 3D NR
- Observe (63px/m)
- 987.5 m
- Recognise (125px/m)
- 500 m
- White Balance
- Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom
- Audio Interface
- 1 input (RCA Port)/ 1 output (RCA Port) / Audio Compression - G.711a; G.711Mu; G726; G.723
- Bit Rate Control
- Constant bit rate (CBR) / Variable bit rate (VBR)
- Edge Storage
- MicroSD Card (up to 256GB) / NAS / Local PC
- ePoE
- No
- Infrared System
- 2 x Infrared LED, 100m range, Auto/manual on/off control
- Lens / Iris
- 5 mm – 125 mm F1.6 ~ F3.6 Motorised Lens with Auto Iris
- Min Illumination
- Color: 0.005lux@F1.6 B/W: 0.0005lux@F1.6 0Lux (IR on)
- Pan/Tilt/Rotation
- Pan: 51.9° ~ 3.0° Tilt: 39.7° ~ 2.2° Rotation: 63.1°–3.7°
- Picture Control
- Flip 180°
- Protocol
- IPv4/IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x
- RAM / ROM
- 128 MB / 512 MB
- S/N Ratio
- ≥ 55 dB
- Smart Scene Adaptive (SSA)
- No
- Streaming Method
- Unicast / Multicast
- Video Interface
- 1 Output (Vpp 75Ω)
- Auto Tracking
- Support
- Modes / Presets
- Up to 300 presets / 5 Pattern, 8 Tour, Auto Pan, Auto Scan
- PTZ Speed
- Pan: 240°/s; Tilt: 160°/s | Manual Pan: 0.1°/s–240°/s Manual Tilt: 0.1°/s–160°/s
- Start-up Action
- Auto-restore to previous PTZ/lens status
- Heat Map
- N/A
- People Counting
- N/A
- Perimeter Protection
- Tripwire & Intrusion (Add recognition of humans & vehicles), Fast Moving Detection, Loitering Detection, Parking & Gathering Detection
- Digital Zoom
- 16x
- Event Triggers
- Motion detection / Video tamper / Scene change / Network disconnection / IP address conflict / Illegal access / Storage anomaly
- Face Capture
- Support
- Face Recognition
- N/A
- Image Stabilisation
- Electronic
- IVS Functions
- Abandoned object / Missing object
- Metadata
- N/A
- Optical Defog
- N/A
- Privacy Masking
- Up to 24 areas
- Region of Interest
- Support
