ALE-PIRB
In Stock - Ready to Ship
$ 240.90
inc-GST
  • Outdoor detection range up to 100m
  • Anti-electromagnetic interference capability, suitable for substations, wireless base stations.
  • Adjustable induction speed and alarm trigger time 35-700msec
  • Optical adjustment angle (H)180° ±90° (V) 20° ±10°
  • Ingress protection: IP55



Watchguard 4x Beam Hardwired IR Motion Detector



ALE-PIRB

2 Years Warranty!



This 100m photoelectric detector uses 4 pulsed infrared beams that are designed to activate an alarm only when 4 beams are simultaneously blocked. The robust IP55 housing of the four photoelectric detectors is designed to provide reliable perimeter security both indoors and out. The transmitters emit invisible infrared beams to the receiver with changing frequencies to protect beams from disturbance.





Product Features:



• Outdoor detection range up to 100m

• Anti-electromagnetic interference capability, suitable for substations, wireless base stations.

• Adjustable induction speed and alarm trigger time 35-700msec

• Optical adjustment angle (H)180° ±90° (V) 20° ±10°

• Ingress protection: IP55

• Dimensions: 370 x 101 x 96mm

Dimensions
370 x 101 x 96mm
Type
Motion Sensor
Tamper Switch
NC, opens when cover is removed
Alarm Output
Relay output NC/NO optional:AC/DC 30V 0.2A max
Alarm Period
2s
Beam
4
Case Material
PC
Certificate
CE certificated
Contact Capacity
AC/DC 30V 0.2A max
Detection
Infrared beam, interruption alarm
Interruption Time
35-700ms (optional)
Operating temperature
-25°C~+55°C
Power
12-24VDC
Waterproof Grade
IP55
Working Current
105mA max
