VIP Vision IP 2MP Residential POE Intercom Door Station (Aluminium) IP65&IK08
- 1/2.8’’ 2.0MP 1.9mm lens camera with 140° FOV
- Built-in microphone and speaker for 2-way talk
- Built-in NFC card reader for keycard access
- Connect with intercom monitor via WiFi or Ethernet
- Door control, alarm and RS485 input/output relays
- Intuitive, easy-to-use interface
- Weather and vandal resistant IP65/IK08 aluminium body
- Power over Ethernet
VIP Vision Aluminium IP Intercom Door Station with WiFi - INTIPDDS2
2MP Camera | WiFi & Ethernet | NFC Keycard Access | Weather & Vandal Resistant
The INTIPDDS2 Aluminium Door Station delivers a modern, secure, and convenient video intercom solution for residential properties. With full WiFi support, 2MP wide-angle camera, NFC keycard access, and durable IP65/IK08 weather and vandal resistance, it’s ideal for single homes, small businesses, or shared building entrances.
Key Features & Benefits
- 2.0MP Wide-Angle Camera — Capture clear, detailed images with 140° field of view and day/night ICR.
- WiFi & Ethernet Connectivity — Flexible installation with reliable wired or wireless networking options.
- Built-in NFC Keycard Reader — Convenient, secure access via contactless NFC cards (supports up to 10,000 cards).
- Two-Way Talk — Integrated microphone and speaker for clear communication with visitors.
- Weather & Vandal Resistant Design — IP65 ingress protection and IK08-rated aluminium construction for durability in harsh conditions.
- Door Control & Alarm Integration — Relay outputs for electronic door strikes, alarm inputs/outputs, and RS485 support.
- Power Options — Supports 12VDC or PoE (802.3af) for flexible installation.
Real-World Applications
Residential Entrances — Improve security and convenience for homeowners with video monitoring and keycard access.
Shared Apartments & Villas — Easily manage guest access with clear video, two-way talk, and secure NFC integration.
Small Business & Offices — Control visitor entry with secure video verification and integrated door release.
Gate & Fence Installations — Durable, weatherproof design ideal for exposed entry points.
Quick Specifications
Camera | 1/2.8’’ 2MP CMOS, 140° Horizontal FOV |
---|---|
Audio | Built-in Microphone & Speaker (2-Way Talk) |
Access Control | NFC Card Reader (10,000 card capacity) |
Connectivity | WiFi & Ethernet (10/100Mbps) |
Power | 12VDC or PoE (802.3af) |
Weather Resistance | IP65 |
Vandal Resistance | IK08 |
Dimensions / Weight | 182 x 101 x 30mm / 0.80kg |
Warranty | 1 Year |
Secure, Smart Entry for Modern Homes — The INTIPDDS2 combines wide-angle video, robust weather protection, and convenient WiFi or wired connectivity, providing peace of mind for your property.
- Dimensions
- 182 x 101 x 30mm
- Main Processor
- Embedded Microprocessor
- Power input
- 12VDC, PoE (802.3af)
- Ingress Protection
- IP65
- Keypad
- 2 Mechanical Buttons
- Weight
- 0.80kg
- Power Consumption
- Standby < 1W / Operation < 7W
- App Connection
- QR Code
- Button Illumination
- None
- Camera System
- 1/2.8’’ 2.0 Megapixel CMOS with 1.9mm lens (Horizontal FoV: 140°)
- Card Support
- Built-in NFC Card Reader, Supports up to 10,000 13.56MHz NFC cards
- Max. Indoor Monitors
- 22 (11 per button)
- Audio / 2-Way Talk
- Omni-directional Microphone & Embedded Loudspeaker for 2-way talk
- Ethernet / Network
- 10M/100Mbps Self-adaptive / TCP/IP protocol
- Input / Output
- 1 x relay for door control / 2 x channel alarm interface / 1 x RS485
- Low-Light Application
- Day/Night ICR
- Series
- D Series
