VIP Vision Entry Series Standalone Analogue INTKIT-A1
VIP Vision Entry Series Standalone Analogue INTKIT-A1
VIP Vision Entry Series Standalone Analogue INTKIT-A1
VIP Vision Entry Series Standalone Analogue INTKIT-A1

VIP Vision Entry Series Standalone Analogue Intercom Kit - INTKIT-A1

INTKIT-A1
In Stock - Ready to Ship
$ 130.90 $ 154.00 -15%
inc-GST
Time left
  • Analogue door station with a 1.3-megapixel camera
  • Slim 7" indoor intercom monitor
  • Single-button door station for visitor ease-of-use
  • Door stations call connected indoor monitors (max. 3)
  • Interface with most electronic door strikes & sensors
  • Ideal for replacing old analogue intercom systems
  • Add an analogue camera for live view through the monitor (not included, CVBS output only)

Various Payment Types at Checkout.

All Payment Options are available at Checkout: Visa/MC/Amex, Zip, Afterpay, Paypal and Bank Dep



VIP Vision Entry Series Standalone Analogue Intercom Kit — INTKIT-A1

Analogue video intercom | 7" indoor monitor | Runs on 4-core cable | Door strike control | Easy retrofit

VIP Vision INTKIT-A1 4-wire analogue intercom kit with 7-inch monitor

Looking to replace a tired old door buzzer or an ageing intercom without rewiring the house? The VIP Vision INTKIT-A1 is a simple, dependable analogue 4-wire / 4-core video intercom kit designed for Australian homes, units and small businesses. It uses the same style of 4-core alarm/communications cable many older systems were wired with, so most retrofits are a straight swap: re-use the cable, mount the new door station, power up the 7" monitor and you’re done. You get clear video, two-way talk and a proper door strike output for gates or front doors — no networking, no apps, no cloud, just a reliable hard-wired intercom that works every time.

Why installers and homeowners pick INTKIT-A1

  • Runs on 4-core cable: perfect for replacing legacy intercoms and doorbells without pulling new Cat cable.
  • Retrofit friendly: re-use existing cable runs and mounting locations, keeping labour and mess to a minimum.
  • 7" indoor monitor: easy push-button operation for answer/hang-up, unlock, volume/brightness and cycling live views.
  • Real door control: interfaces with most 12 V electronic door strikes and door sensors for secure entry.
  • Expandable: supports up to three indoor monitors and an additional door station, so you can add the kitchen and master bedroom later.
  • Optional extra camera (CVBS): add an analogue CCTV camera for live view from the monitor (e.g. driveway or shed).
  • No internet required: works during home network outages and doesn’t rely on a phone app.

How it connects (simple 4-wire)

The kit uses a classic four-wire link between the door station and the indoor monitor for power, video and audio. For typical domestic runs up to ≈50 m, a standard 0.75 mm² 4-core cable is recommended. Longer runs can be achieved by using a coaxial feed for the video leg with the power/audio cores alongside. The included 12 V DC 2 A power supply is suited to a one door station + one monitor setup; if you add devices, match the PSU to the device count (e.g. 3 devices → 12 V 3 A).

Real-life uses around the home and business

  • Front door upgrade: swap out an old chime so you can see and speak with visitors before you unlock.
  • Granny flat or dual occupancy: run a monitor in the main residence and another in the granny flat for quick communication.
  • Gate control: pair with a 12 V electric strike or gate relay to buzz in deliveries from the kitchen monitor.
  • Shops & counters: keep the door locked while you verify visitors — ideal for chemists, jewellers and after-hours retail.
  • Workshops & back-of-house: call through from the roller door or side access; add a second monitor in the office.
  • Apartments & small blocks: retrofits nicely where there’s an existing 4-wire riser; simple, low-maintenance, no app training.

What it is: a dependable analogue 4-wire intercom with video, two-way audio, and a door strike output that you can expand with extra monitors and an optional CVBS camera.

What it isn’t: a smart/IP intercom — there’s no smartphone app or remote viewing. If you need cloud/app features, choose a VIP Vision IP intercom series instead.

Fitting notes (quick install tips)

  • Shelter the door station: mount under an eave or hood; seal around the cable entry to prevent water ingress.
  • Strike wiring: confirm strike voltage/current and polarity; use a suitable 12 V supply path and observe door sensor wiring if fitted.
  • Cable runs: keep the 4-core away from noisy mains runs; for longer distances, use coax for the video leg as required.
  • Expand cleanly: when adding a second/third monitor, upsize the PSU (e.g. 4 devices → 12 V 4 A) for reliable operation.

Features at a glance

  • Analogue 1.3 MP door station with single call button for visitor ease-of-use.
  • Slim 7" indoor monitor with physical controls for answer/hang-up, unlock, settings and live view cycling.
  • Supports up to 3 indoor monitors and 2 door stations in a small site.
  • CVBS camera input on the monitor for an additional analogue camera view (driveway, shed, side gate).
  • 12 V DC operation; kit includes a 12 V 2 A PSU for a single door station + single monitor setup.
  • Low total cost of ownership: no cloud subscriptions, no Wi-Fi setup, minimal training for the household.

VIP Vision INTKIT-A1 Datasheet Page 1

VIP Vision INTKIT-A1 Datasheet Page 2

FAQs

Does it work with my existing cable? If your old system used a 4-core cable between door and monitor, you’re in luck — that’s exactly what this kit expects. For longer runs over roughly 50 m, use a coaxial video leg with the power/audio cores.

Can I add more monitors later? Yes. You can expand to three indoor monitors. Just upgrade the power supply to match the total device count.

Will it unlock my existing 12 V strike? In most cases yes. Check the strike’s power requirements and wiring diagram. A licensed sparky can confirm compatibility on site.

Can I check it from my phone? No — this is an analogue intercom with no app or cloud features. If you require mobile notifications or remote unlock, look at VIP Vision’s IP intercom range.

Also called by customers

analogue intercom kit, 4-wire intercom, 4-core intercom, retrofit intercom, door strike intercom, video door phone, hard-wired intercom, granny flat intercom, shop counter intercom, driveway gate intercom. If you need Wi-Fi or app control, search for IP video intercom instead.

What’s in the box

  • 1 × Door station (1.3 MP camera)
  • 1 × 7" indoor monitor
  • 1 × Door station mounting bracket
  • 1 × 12 V DC power supply
  • 1 × Screw kit & installation guide
  • 1 × Quick start manual

In stock with fast Australia-wide shipping. Choose the INTKIT-A1 when you want a straight-swap 4-core cable retrofit with video, talk and unlock — no Wi-Fi headaches, just a solid intercom that gets the job done.
