Mercusys MS108GP | 8-Port Gigabit Desktop PoE Switch • 7 × PoE+ • 65 W Budget
Key Features
- 8 × 10/100/1000 Mb/s RJ-45 ports — 7 PoE+ (Ports 1-7) + 1 uplink
- 65 W Total PoE Budget* – up to 30 W per PoE port (IEEE 802.3af/at)
- Extend Mode – 250 m PoE run for remote IP cameras*
- Isolation (VLAN) Mode – one-touch traffic separation for smooth, secure NVR playback
- PoE Auto-Recovery – watchdog automatically reboots frozen PDs
- Fan-less Metal Chassis – silent & resilient, ideal for office or retail
- 100 % Plug-and-Play – no software, no configuration, no headaches
Seven PoE+ Ports (65 W) — Ready for Complete Surveillance & Wi-Fi Roll-outs
Power over Ethernet — Two Cables in One
- No Fuss: Deploy IP cameras & APs without electricians.
- Cost-Efficient: Remove extra power points & adapters.
- Flexible Placement: Install devices exactly where coverage is best.
- Smart Power Management: Protects equipment from overload & surges.
- 802.3af/at Compatible: Works with virtually any PoE PD.
Real-World Applications
- Seven-camera VIGI or Tapo surveillance kits for cafés, salons & convenience stores
- Campus Wi-Fi 6 AP clusters with a single uplink to the core router
- VoIP phone banks & meeting-room touch panels that need silent operation
- Gate intercom & PTZ camera pairs over 250 m “Extend Mode” runs*
- IoT edge devices – smart-lighting controllers, RFID readers, environmental sensors
| Specification |
Details |
| Ports |
8 × Gigabit RJ-45 (7 × PoE+, 1 × uplink) |
| PoE Budget* |
65 W total / 30 W max per PoE port |
| Extend Mode |
250 m @ 10 Mb/s on PoE ports |
| Switching Capacity |
16 Gb/s |
| Housing / Cooling |
Metal, fan-less passive cooling |
| Operating Temp |
0 °–40 °C | 10 %–90 % RH |
| Storage Temp |
-40 °–70 °C | 5 %–95 % RH |
Package Contents
- MS108GP 8-Port Gigabit PoE+ Switch
- 12 V / 1.5 A Power Adapter
- Quick Installation Guide
* PoE budget & extend-mode distance are based on laboratory testing. Results vary with cable quality, ambient temperature and total PD load.
