TP-Link Omada 24-Port Gigabit Rackmount Switch - DS1024G
- 24× Gigabit RJ45 ports
- Supports MAC address self-learning and auto MDI/MDIX
- Standard 19-inch rack-mount steel case
- One-click Isolation Mode for improved security and performance
- Loop prevention feature helps detect and resolve network loops
- Plug & Play setup, no configuration needed
TP-Link Omada DS1024G 24-Port Gigabit Unmanaged Switch
24× Gigabit Ports | Plug & Play | Durable Metal Housing | Rackmount or Desktop Installation | Fanless Silent Design
The TP-Link Omada DS1024G is a high-performance, 24-port unmanaged switch designed to expand your wired network with full Gigabit speeds. Its robust metal construction, fanless design, and rackmount compatibility make it ideal for small businesses, offices, and high-speed LAN expansion.
Key Features & Benefits
- 24× Gigabit Ports — Provides fast, stable wired connections for high-performance networks.
- Plug & Play Simplicity — No configuration required; automatic detection of speed and duplex mode.
- High Switching Capacity — 48 Gbps total switching bandwidth ensures smooth traffic handling.
- Fanless Silent Operation — Ideal for offices, workstations, or noise-sensitive environments.
- Durable Metal Housing — Sturdy construction for enhanced reliability and longevity.
- Desktop & Rackmount Options — Flexible deployment to suit server rooms or workspaces.
- Reliable Non-Blocking Architecture — Maximises throughput for all connected devices.
- Energy-Efficient Design — Reduces power consumption automatically based on link status.
Real-World Applications
Small to Medium Office Networks — Expand LAN infrastructure with high-speed, reliable connectivity.
Surveillance Systems — Supports networked IP cameras, NVRs, and monitoring equipment.
Server Rooms & IT Racks — Rackmount-compatible for structured installations.
Workgroup Connectivity — Ideal for connecting computers, printers, and network devices in workspaces.
Technical Specifications
- Ports: 24× Gigabit RJ45 (10/100/1000 Mbps)
- Switching Capacity: 48 Gbps
- Packet Forwarding Rate: 35.7 Mpps
- MAC Address Table: 8K entries
- Fanless Design: Silent operation
- Housing: Metal
- Mounting: Rackmount kit included; desktop option
- Dimensions: 294 × 180 × 44 mm
- Energy-Efficient: IEEE 802.3az compliant
Simple, Scalable Network Expansion — The DS1024G is the perfect solution for expanding your wired LAN with reliable Gigabit speeds, silent performance, and flexible installation options for growing networks.
