Watchguard Standalone IP55 Access Control Reader
ACRDR100
The ACRDR100 is a weather-resistant, ABS plastic, self-contained access control reader designed to directly drive electric door locks. It is capable of accommodating up to 500 user RFID cards/keyfobs and is compatible with both fail-safe and fail-secure locks. The door lock striking timer is programmable for access customisation.
A built-in door chime relay contact is available to operate an external low power door chime. The reader uses a solid-state switch instead of a mechanical relay contact for door lock strikes to improve service life. It also features a tamper switch and unauthorised access lock for vandal protection.
The ACRDR100 has a built-in Data I/O bus, enabling up to 3 additional ACRDR100s to be used in a multi-station access control configuration. The reader comes standard with 2 RFID cards and is also compatible with the entire range of proximity keys and cards.
Product Features:
- • Interfaces with most electric door locks
- • Compatible with fail-safe or fail-secure locks
- • Ideal for offices and for small business
- • Expand with up to 3 additional readers
- • Handles up to 500 users & 5 super-users
- • Built-in door chime & tamper relay contact
Specifications:
| Access Lock Modes |
No lock / 60s after 10 attempts / 15 mins after 10 attempts |
| Data I/O Bus |
Up to 3 additional readers |
| Dimensions |
119 x 60 x 23mm |
| Door Chime |
1A / 24VDC (N.O. relay, dry contact) |
| Door Lock Control |
Time: 1 ~ 60 seconds |
| Ingress Protection |
IP55 (dust protected & water ingress resistant) |
| Material & Finish |
Matte grey ABS plastic / Black gloss front |
| Maximum User Access |
500 (user) / 5 (super-user) ; keyfobs, cards |
| Operating Current |
60mA (standby) / 80mA (active) |
| Operating Environment |
-20°C ~ 70°C / RH95% (max) |
| Power Input |
12VDC |
| Solid State Door Lock |
3A / 16VDC |
| Tamper Switch |
50mA / 12VDC (N.C. relay, dry contact) |
| Weight |
0.16kg |
| Warranty (Years) |
1 |
