VIP Vision Professional AI 32 Channel Network Video Recorder with ePoE (320Mbps)
- Record beyond Ultra HD up to 16.0MP (4920 x 3264)
- Up to 320Mbps incoming bandwidth, H.265+ support
- Decode up to 4 channels at 4K / 16 channels at 1080p (30fps)
- 4 x SATA 14TB HDD support for up to 56TB footage storage
- 16 x Built-in PoE switch (8 x ePoE ports, 800m@10Mbps using ePoE cameras)
- Native Ultra HD live view on 4K monitors via HDMI
- Identify people in real-time with up to 16 channels of face recognition
VIP Vision Professional AI 32 Channel Network Video Recorder with ePoE (320Mbps)
NVR32PRO16P-I2
The NVR32PRO16P-I2 offers advanced technologies to transform the way surveillance works for you. Monitor your operations with greater efficiency, security & reliability using face recognition and AI-powered people & vehicle detection. Identify strangers, set up face whitelists & blacklists, search playback by face and receive people and vehicle surveillance alerts to your devices.
Product Features:
• Record beyond Ultra HD up to 16.0MP (4920 x 3264)
• Up to 320Mbps incoming bandwidth, H.265+ support
• Decode up to 4 channels at 4K / 16 channels at 1080p (30fps)
• 4 x SATA 14TB HDD support for up to 56TB footage storage
• 16 x Built-in PoE switch (8 x ePoE ports, 800m@10Mbps using ePoE cameras)
• Native Ultra HD live view on 4K monitors via HDMI
• Identify people in real-time with up to 16 channels of face recognition (with Ultimate AI cameras)
• AI-powered perimeter protection, up to 12 channels of people & vehicle detection
• Receive face recognition & perimeter alerts on your device
- Dimensions
- 440mm × 411mm × 76mm
- Power Supply
- Single, AC100V~240V, 50~60 Hz
- Audio
- 1 channel input (RCA), 1 channel output (RCA)
- Operating Environment
- -10°C ~ +55°C / 0 ~ 90%RH / 86 ~ 106kpa
- Weight
- 5.00kg (without HDD)
- Display Split
- 1st screen - 1/4/8/9/16/25/36, 2nd screen - 1/4/8/9/16
- Network Functions
- HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, Easy4ip
- Power Consumption
- Rackmount Units
- 1.5U
- Rackmountable
- Yes
- Video Input
- 32 Channels
- Interoperability
- ONVIF 2.4, SDK, CGI
- PoE
- Yes
- Recording Resolution
- Configurable from: 24.0MP (6016 x 4016) to D1 (704 x 480)
- Alarm Actions
- Begin record, take snapshot, camera external alarm output, access controller, audio, buzzer, NVR log, camera preset, email
- Alarm Interface
- 16 channels input, 6 channels output
- Alarm Types
- General (motion, video loss, scene change, etc.), Anomalies (camera disconnect, disk full, IP conflict , etc.), Intelligent (AI alerts, face, human/vehicle, etc.)
- ANPR (By Camera)
- 8 channels
- ANPR Functions
- Up to 20,000 plate numbers, blocklist & allowlist
- App Integration
- iOS / Android
- Backup Method
- USB device / Network / eSATA
- Decoding Capacity (AI Disabled)
- [email protected]/25fps, 16CH@1080P/25fps
- Decoding Capacity (AI Enabled)
- [email protected]/25fps, 16CH@1080P/25fps
- Display Mode
- Multiple sources: HDMI1+VGA (Mirror), HDMI2
- Display Output
- 2 x HDMI (up to 3840 x 2160), 1 x VGA (up to 1920 x 1080)
- Face Detection (By Camera)
- 16 channels
- Face Detection (By NVR)
- 4 channels (up to 12 face images per second, per channel)
- Face Detection Functions
- Gender, Age Group, Glasses, Expressions, Face Mask, Beard
- Face Recognition (By Camera)
- 16 channels
- Face Recognition (By NVR)
- 4 channel (Face detection via NVR video stream analysis; Face recognition performed by NVR) 16 channels (Face detection performed via Face Capture cameras via image stream; Face recognition performed via NVR)
- Face Recognition Capacity
- NVR Supports up to 20 face databases and 20,000 face images
- HDD
- 4 x SATA bays, up to 16TB per bay
- HDD Capacity
- 4
- Human/Vehicle Detection (By Camera)
- IVS: 16 channels, SMD: 16 channels
- Human/Vehicle Detection (By NVR)
- IVS: 12 channels (10 rules per channel), SMD: 12 channels
- Human/Vehicle Detection Functions
- AI Tripwire & Intrusion (IVS), AI Motion Detection (SMD)
- Network Bandwidth (AI Disabled)
- 320Mbps (incoming/recording/outgoing)
- Network Bandwidth (AI Enabled)
- 160Mbps (incoming/recording/outgoing)
- Network Input
- 1 x 1000Mbps Ethernet uplink, 16 x PoE 100Mbps (802.3af/at), ports 1-8 supports ePoE
- NVR Operated AI
- Face Detection, Face Recognition, AI Human/Vehicle Detection, Video Metadata
- Playback Channels
- Up to 16 channels
- Playback Modes
- General Recording, Motion Detection, Intelligent Events, Alarm Triggers, POS
- Processor & Operation
- Industrial-grade processor, Embedded Linux OS, Web Interface / Local GUI
- Supported Camera AI
- Face Detection, Face Recognition, AI Human/Vehicle Detection, ANPR, People Counting, Heatmap, Video Metadata
- USB & Other Inputs
- 1 x Front USB 2.0, 2 x Rear USB 3.0 / 1 x RS-485, 1 x RS-232, 1 x eSATA
- Video & Audio Compression
- Video: Smart H.265+ / H.265 / H.264 / H.264+ / MJPEG, Audio: G.711a / G.711u / PCM / G726
- Video Metadata (By Camera)
- 8 channels
- Video Metadata (By NVR)
- 4 channels
- Video Metadata Functions
- People (clothing colour, hat, bag, umbrella, etc.), Vehicle (vehicle colour, vehicle model, number plate, etc.)
VIP Vision is backed by over 2,000 professionals in research and development at the forefront of advanced surveillance and IP intercom technologies. Their constant pursuit of innovation delivers cutting edge products with high quality, performance and reliability.
With 4 to 128 channel systems, VIP Vision offers professional video surveillance solutions for small projects through to large commercial, public sector and government level applications.
Stream beyond Ultra HD with 12 megapixel recording using the latest range of VIP Vision IP surveillance cameras. Adaptable to any task, the range offers a wide selection of professional bullet and dome cameras, as well as application specific models such as PTZ, fisheye and pinhole cameras.
VIP Vision IP systems are accompanied by an extensive range of accessories including, video wall controllers, brackets & adapters, central management software and PoE accessories to help you deliver the most professional and reliable install possible.
Rest assured knowing you have usable video evidence when it matters most with VIP Vision IP surveillance.
