VIP Vision 8-port Unmanaged Fast PoE Ethernet Switch - VSPOE-SW8H
- 8 x PoE+ device ports with 100Mbps per port
- 1 x Hi-PoE device port with 100Mbps per port
- 1 x 1000Mbps Gigabit RJ45 & SFP fibre uplink ports
- Total PoE power load up to 96W
- Unmanaged switch for plug and play applications
- DIN rail mountable for neat rackmount installations
- Professional appearance full metal enclosure
VIP Vision 8-port Unmanaged Fast PoE Ethernet Switch
VSPOE-SW8H
4 Years Warranty!
The VSPOE-SW8H is a DIN rail mountable, fast PoE switch in 8 ports. It is ideal for building secondary networks - providing data and power to devices on the edge of a network, such as CCTV cameras, wireless access points, IP telephones, network access control systems and more.
Product Features:
• 8 x PoE+ device ports with 100Mbps per port
• 1 x Hi-PoE device port with 100Mbps per port
• 1 x 1000Mbps Gigabit RJ45 & SFP fibre uplink ports
• Total PoE power load up to 96W
• Unmanaged switch for plug and play applications
• DIN rail mountable for neat rackmount installations
• Professional appearance full metal enclosure
- Dimensions
- 150 x 100 x 42mm
- Operating Environment
- -30°C~65°C / RH5%~95%
- Weight
- 0.54kg
- Ports
- 8 ports
- PoE
- Yes
- Mounting Options
- DIN rail
- DHCP
- N/A
- PoE Protocol
- PoE (IEEE802.3af) / PoE+ (IEEE802.3at) / Hi-PoE
- Device Ports
- 8 x 10/100 Base-T (PoE power supply ports)
- Exchange Mode
- Store & forward
- Extend Mode
- N/A
- Flow Control
- Enabled
- Input Power
- 48 ~ 57VDC
- Lightning Protection
- Common Mode: 6kV / Differential Mode: 4kV
- LLDP
- N/A
- MAC Address Capacity
- 8K
- Network Management
- N/A
- Network Time Protocol
- N/A
- Packet Forwarding Rate
- 4.17Mpps
- PoE Management
- N/A
- Port Aggregation
- N/A
- Port Mirroring
- N/A
- Quality of Service
- N/A
- Security Features
- N/A
- Spanning Tree Protocol
- N/A
- Speed
- Fast 10/100
- Switch Management
- Unmanaged
- Switch Power Load
- Ports 1-2: ≤60W / Port 3-8: ≤30W (Total: ≤96W)
- Switching Capacity
- 7.6Gbps
- System Maintenance
- N/A
- Uplink Ports
- 1 x 100/1000 Base-X / 1 x 10/100/1000 Base-T
- Virtual LAN
- N/A
