VIP Vision 4-Port Unmanaged PoE Switch - VSPOE-SWA4L

VSPOE-SWA4L
In Stock - Ready to Ship
$ 53.46
inc-GST

or 4 interest-free payments of $13.37 with

  • 4 x 10/100 PoE ports
  • Up to 30W per port, 60W total PoE budget
  • PoE (802.3af) and PoE+ (802.3at)
  • 1 x 10/100 uplink port
  • Unmanaged: plug and play



VIP Vision 4-Port Unmanaged PoE Switch

4 Years Warranty!

VSPOE-SWA4L

A simple, plug-and-play PoE switch for small camera systems. It powers up to four cameras or devices over the network cable, with no setup required.

Features:

• 4 x 10/100 PoE ports

• Up to 30W per port, 60W total PoE budget

• PoE (802.3af) and PoE+ (802.3at)

• 1 x 10/100 uplink port

• Unmanaged: plug and play

• Built-in lightning protection

Ideal for:

Small CCTV systems, extending a recorder, and powering access control readers, intercoms or WiFi access points.

Full specifications are listed in the Data Sheet tab. Need help choosing or planning an install? Our technical team at InFront Technologies is happy to help.

Dimensions
170 x 100 x 35mm
Operating Environment
-10°C~55°C / RH10%~90%
Weight
0.5kg
Ports
4 ports
PoE
Yes
Mounting Options
N/A
DHCP
N/A
Management
N/A
PoE Protocol
PoE (IEEE802.3af) / PoE+ (IEEE802.3at)
Device Ports
4 x 10/100 Base-T (PoE power supply ports)
Exchange Mode
N/A
Extend Mode
N/A
Flow Control
N/A
Input Power
AC100~240V
Lightning Protection
Common Mode: 2kV / Differential Mode: 1kV
LLDP
N/A
MAC Address Capacity
1K
Network Management
N/A
Network Time Protocol
N/A
Packet Forwarding Rate
744Kpps
PoE Management
N/A
Port Aggregation
N/A
Port Mirroring
N/A
Quality of Service
N/A
Security Features
N/A
Spanning Tree Protocol
N/A
Speed
Fast 10/100
Switch Management
Unmanaged
Switch Power Load
Ports 1-4: ≤30W (Total PoE Load: ≤60W)
Switching Capacity
1Gbps
System Maintenance
N/A
Uplink Ports
1 x 10/100 Base-T
Virtual LAN
N/A
