VIP Vision 16 Port Unmanaged Gigabit Ethernet Switch - VSETH-SW16G
- 16 x 10/100/1000Mbps Base-T Ethernet ports
- Unmanaged switch for affordability & ease of use
- LED indicators for the display of information
- Rackmount switch with included cabinet tabs
- Professional appearance full metal enclosure
- Lightning overvoltage protection up to 6kV
- 100 ~ 240VAC input power
VIP Vision 16 Port Unmanaged Gigabit Ethernet Switch
VSETH-SW16G
The VSETH-SW16G is a 16-port Gigabit Ethernet switch that offers high speed data transmission and reliability. It is rackmount ready and is ideal for building gigabit network infrastructure for businesses.
Product Features:
• 16 x 10/100/1000Mbps Base-T Ethernet ports
• Unmanaged switch for affordability & ease of use
• LED indicators for display of information
• Rackmount switch with included cabinet tabs
• Professional appearance full metal enclosure
• Lightning overvoltage protection up to 6kV
• 100 ~ 240VAC input power
- Dimensions
- 294 x 178 x 44mm
- Operating Environment
- 0° ~ +40°C
- Weight
- 1.36kg
- Ports
- 16 ports
- PoE
- No
- Mounting Options
- Rackmount Tabs (1RU)
- DHCP
- N/A
- PoE Protocol
- N/A
- Device Ports
- 16 x 10/100/1000 Base-T
- Exchange Mode
- Store & foward
- Extend Mode
- N/A
- Flow Control
- N/A
- Input Power
- 100 ~ 240VAC
- Lightning Protection
- Common Mode: 6KV / Differential Mode: 0.5V
- LLDP
- N/A
- MAC Address Capacity
- 8K
- Network Management
- N/A
- Network Time Protocol
- N/A
- Packet Forwarding Rate
- 23.8Mbps
- PoE Management
- N/A
- Port Aggregation
- N/A
- Port Mirroring
- N/A
- Quality of Service
- N/A
- Security Features
- N/A
- Spanning Tree Protocol
- N/A
- Speed
- Gigabit 10/100/1000
- Switch Management
- Unmanaged
- Switch Power Load
- N/A
- Switching Capacity
- 32Gbps
- System Maintenance
- N/A
- Uplink Ports
- N/A
- Virtual LAN
- N/A
