VIP Vision 4-port Unmanaged Fast PoE Ethernet Switch - VSPOE-SW4H

VSPOE-SW4H
In Stock - Ready to Ship
$ 119.90
inc-GST
  • 3 x PoE+ device ports with 100Mbps per port
  • 1 x Hi-PoE device port with 100Mbps per port
  • 1 x 1000Mbps Gigabit RJ45 & SFP fibre uplink ports
  • Total PoE power load up to 96W
  • Unmanaged switch for plug and play applications
  • DIN rail mountable for neat rackmount installations
  • Professional appearance full metal enclosure



VIP Vision 4-port Unmanaged Fast PoE Ethernet Switch



VSPOE-SW4H



4 Years Warranty!



The VSPOE-SW4H is a DIN rail mountable, fast PoE switch in 4 ports. It is ideal for building secondary networks - providing data and power to devices on the edge of a network, such as CCTV cameras, wireless access points, IP telephones, network access control systems and more.



Product Features:



• 3 x PoE+ device ports with 100Mbps per port

• 1 x Hi-PoE device port with 100Mbps per port

• 1 x 1000Mbps Gigabit RJ45 & SFP fibre uplink ports

• Total PoE power load up to 60W

• Unmanaged switch for plug and play applications

• DIN rail mountable for neat rackmount installations

• Professional appearance full metal enclosure




Dimensions
150 x 108 x 30mm
Operating Environment
-30°C~65°C / RH5%~95%
Weight
0.44kg
Ports
4 ports
PoE
Yes
Mounting Options
DIN rail
DHCP
N/A
PoE Protocol
PoE (IEEE802.3af) / PoE+ (IEEE802.3at) / Hi-PoE
Device Ports
4 x 10/100 Base-T (PoE power supply ports)
Exchange Mode
Store & forward
Extend Mode
N/A
Flow Control
N/A
Input Power
48 ~ 57VDC
Lightning Protection
Common Mode: 6kV / Differential Mode: 4kV
LLDP
N/A
MAC Address Capacity
8K
Network Management
N/A
Network Time Protocol
N/A
Packet Forwarding Rate
3.57Mpps
PoE Management
N/A
Port Aggregation
N/A
Port Mirroring
N/A
Quality of Service
N/A
Security Features
N/A
Spanning Tree Protocol
N/A
Speed
Fast 10/100
Switch Management
Unmanaged
Switch Power Load
Ports 1: ≤60W / Port 2-4: ≤30W (Total: ≤60W)
Switching Capacity
6.8Gbps
System Maintenance
N/A
Uplink Ports
1 x 100/1000 Base-X / 1 x 10/100/1000 Base-T
Virtual LAN
N/A
