VIP Vision Unmanaged 4-Port PoE Switch (Fast Ethernet 10/100) with 2× Uplink Ports — VSPOE-SWA4U
Model VSPOE-SWA4U
The VIP Vision VSPOE-SWA4U is a compact, unmanaged Fast Ethernet (10/100Mbps) PoE+ switch built for simple edge deployments. It provides 4× PoE+ device ports for powering and connecting CCTV cameras, wireless access points, IP phones and access control devices, plus 2× 10/100Mbps uplink ports for network backhaul.
With plug-and-play operation, a full metal enclosure, included 53VDC power supply and Extend mode up to 250m (10Mbps), it’s an ideal choice for quick installs where reliable PoE delivery matters.
Key Features & Benefits
- 4× Fast PoE+ 10/100Mbps RJ45 device ports for powered edge devices.
- 2× Fast 10/100Mbps RJ45 uplink ports for simple network connectivity.
- PoE+ up to 30W per port with 60W total PoE power load.
- Unmanaged switch — true plug-and-play deployment.
- Extend mode up to 250m PoE range (10Mbps transfer rate in extend mode).
- Professional full metal enclosure for durability at the edge.
- 53VDC power supply included for fast installation.
- Lightning overvoltage protection up to 6kV for added resilience.
- Fast switching performance for cameras, phones, APs and access systems.
Simple PoE+ switching for edge devices.
Power and connect 4 devices with two dedicated uplinks and optional long-range PoE via Extend mode.
Real-World Applications
CCTV Installations — power multiple cameras at the edge with a clean, compact switch.
Small Network Extensions — add powered ports where you need them without configuration.
Remote Runs — use Extend mode up to 250m for longer PoE cable distances (10Mbps in extend mode).
VoIP & Wi-Fi — power IP phones and access points in small offices or branch sites.
Quick Specs
| Switch Type |
Unmanaged PoE/PoE+ Switch (Fast Ethernet) |
| Device Ports |
4× 10/100Mbps RJ45 (PoE) |
| Uplink Ports |
2× 10/100Mbps RJ45 |
| PoE Standards |
IEEE 802.3af (PoE) / IEEE 802.3at (PoE+) |
| PoE Power Budget |
Up to 30W per port / Up to 60W total |
| Switching Capacity |
1.2 Gbps |
| Packet Forwarding Rate |
0.893 Mpps |
| Extend Mode |
Up to 250m range at 10Mbps |
| Input Power |
53VDC |
| Lightning Protection |
Common Mode: 6kV / Differential Mode: 1kV |
| Dimensions |
115.5 × 84.3 × 27 mm |
| Weight |
0.19 kg |
| Warranty |
4 Years |
What’s in the Box
- 1× VIP Vision VSPOE-SWA4U unmanaged 4-port PoE switch
- 53VDC power supply
Choose the VSPOE-SWA4U for simple, reliable PoE+ connectivity with 4 powered ports, dual uplinks and optional 250m Extend mode.
