Seagate SkyHawk 2TB surveillance hard drive (ST2000VX008): a 3.5 inch SATA drive built for 24×7 recording in DVRs and NVRs.
- ✓2TB, 3.5 inch SATA 6Gb/s, 64MB cache
- ✓Rated for 180TB a year, 24×7 recording
- ✓Up to 64 HD cameras, recorders up to 8 bays
- ✓1,000,000 hours MTBF
- ✓Seagate 3-year limited warranty
Description

2TB for the recorder.
Built for 24×7 video.
HD2TBSV is a Seagate SkyHawk 2TB surveillance hard drive, model ST2000VX008 on the label in our photos. It is a standard 3.5 inch SATA drive made to record video around the clock in DVRs and NVRs.
In one sentence: HD2TBSV is a Seagate SkyHawk 2TB 3.5 inch SATA 6Gb/s surveillance hard drive (ST2000VX008) rated by Seagate for 180TB a year, up to 64 HD cameras and recorders with up to 8 drive bays.
The drive only. Your recorder holds and powers it.
This listing is one bare 3.5 inch SATA drive. Our photos and Seagate's datasheet are for model ST2000VX008. Seagate has released newer 2TB SkyHawk models since, so if your job needs a specific model number, confirm the model with us before you order.
- Seagate SkyHawk 2TB 3.5 inch SATA hard drive
- A DVR or NVR with a free 3.5 inch SATA bay
- The SATA data and power leads in that bay
- Four 6-32 UNC mounting screws, if your recorder's bay uses screws
Made to write video all day.
Seagate's ImagePerfect firmware and ATA streaming support are aimed at always-on recording from up to 64 HD cameras. The drive is rated for 180TB of data a year and 8,760 power-on hours, which is 24 hours a day, every day.

Front
A standard 3.5 inch drive.
146.99 × 101.85 × 26.11 mm and about 610 g. It fits any recorder bay made for a 3.5 inch SATA drive, and connects at SATA 6Gb/s.

Case
Side or bottom mounting.
Seagate allows any orientation, using four 6-32 UNC screws in the side holes or the bottom holes. Seagate uses tarnish-resistant components to help protect the drive from the environment.

Underside
SATA data and power at one end.
The standard SATA data and power connectors take the leads already in your recorder. The drive runs from the recorder's 5 V and 12 V supply: about 5.6 W while recording and 4.0 W at idle.
How it goes in
From box to recording.
01
Power the recorder off
Shut it down from its menu, then unplug the power. Handle the drive by its edges, on an antistatic surface.
02
Fit the drive
Plug in the SATA data and power leads, then fix it with four 6-32 UNC screws. Do not overtighten them (Seagate's limit is 6 inch-pounds).
03
Initialise it
Power up and open the recorder's storage or HDD menu. Format or initialise the new drive there; this erases anything on it.
04
Check it is recording
Confirm the drive shows as normal, set the recording schedule or motion recording, then play back a clip to check.
At a glance
HD2TBSV (Seagate ST2000VX008)
Show specs
Capacity
2TB
Seagate model
ST2000VX008 (confirm the model with us if it matters for your job)
Interface
SATA 6Gb/s, 3.5 inch
Cache
64MB
Spindle speed
Not published; Seagate calls it a low-RPM design, average latency 5.1 ms
Max. sustained transfer rate
180MB/s
Drive bays supported
Up to 8
Cameras supported
Up to 64 HD cameras
Workload rate limit
180TB per year
Power-on hours
8,760 per year (24×7)
MTBF
1,000,000 hours
Non-recoverable read errors
1 per 10E14 bits read, max
Load/unload cycles
300,000
RV sensors / SkyHawk Health Management
Not on this model
Power
Start-up 1.8 A at 12 V; 5.6 W operating; 4.0 W idle; 0.5 W standby and sleep
Temperature
0 °C ambient minimum; 70 °C drive case maximum; −40 °C non-operating
Size and weight
146.99 × 101.85 × 26.11 mm; 610 g
Warranty
Seagate 3-year limited warranty
Rescue data recovery
Not included (Seagate offered an optional 2-year plan for this range)

Seagate's mounting drawing for the 2TB and 3TB SkyHawk: 146.99 × 101.85 × 26.11 mm max. Three 6-32 UNC holes each side and four underneath, 3.56 mm maximum screw depth.
Pair it with
Recorders that take a 3.5 inch SATA drive
IVSEC
IVSEC NVR 8000, 8 channels
One 3.5 inch SATA bay up to 16TB and eight PoE+ ports. A 2TB drive suits a replacement or a No HDD order.
Dahua
DHI-NVR4108HS-8P-AI/ANZ
Dahua WizSense 8-channel NVR with 8 PoE ports and one SATA bay up to 20TB.
Uniview
NVR501-08B-P8-IQ
Uniview 8-channel 4K NVR with 8 PoE ports and one SATA bay up to 24TB.
Kit
Dahua DH-K8086T-67 kit
Six 8MP dual-light turrets with an NVR4108HS-8P-AI/ANZ. Ordered with No HDD, it needs a SATA drive like this one.
Where it is used
Where a 2TB SkyHawk fits.
Home recorders
A 4 or 8 channel NVR or DVR watching the driveway, doors and yard.
Replacing a failed drive
Swap out a dead or noisy drive in an existing recorder that takes 3.5 inch SATA.
Small shops
A counter, door and stockroom camera set on a single-bay recorder.
Offices and receptions
A small office recorder covering the entry, reception and car park.
Sheds and farm buildings
A recorder in the shed or workshop covering gates, machinery and fuel.
Installer spares
A spare drive on the shelf for quick service calls on small systems.
SkyHawk 2TB or 4TB
| ST2000VX008 (2TB, this drive) | ST4000VX007 (4TB) | |
|---|---|---|
| Capacity | 2TB | 4TB |
| Drive bays supported | Up to 8 | Up to 16 |
| RV sensors | No | Yes |
| SkyHawk Health Management | No | Yes |
| Max. sustained transfer rate | 180MB/s | 190MB/s |
| Cache | 64MB | 64MB |
| Average operating power | 5.6 W | 5.5 W |
| Workload, MTBF, warranty | 180TB/yr, 1M hours, 3 years | 180TB/yr, 1M hours, 3 years |
Both columns come from Seagate's SkyHawk 3.5 inch datasheet DS1902.12 (June 2019). We also sell a 4TB SkyHawk; confirm its model number with us.
Common questions
Which Seagate model is this?
The label in our photos and Seagate's datasheet show the ST2000VX008, a 2TB SkyHawk. Seagate has released newer 2TB SkyHawk models since, so if you need a specific model number, confirm the model with us before ordering.
Will it fit my recorder?
Yes, if the recorder has a free 3.5 inch SATA bay. It is a standard 3.5 inch SATA 6Gb/s drive, 146.99 × 101.85 × 26.11 mm. Check the recorder's largest drive per bay; 2TB is within the limit of the Dahua, IVSEC and Uniview recorders listed on this page.
How many cameras can it record?
Seagate rates it for up to 64 HD cameras. In practice the recorder's channel count and incoming bandwidth set the limit.
How many days of footage will it hold?
We don't quote a number of days, because it depends on the number of cameras, resolution, compression and how much motion is recorded. Your recorder's settings, or its maker's storage calculator, give an estimate for your setup.
Can I use it in a recorder with more than 8 bays?
Seagate rates this 2TB model for systems with up to 8 drive bays, and it has no RV sensors. For bigger recorders, the 4TB SkyHawk (up to 16 bays) or a SkyHawk AI drive is the better match.
What is the workload rating?
180TB a year, with 8,760 power-on hours a year, which means 24 hours a day, every day. MTBF is 1,000,000 hours.
What warranty does it have?
Seagate gives the ST2000VX008 a 3-year limited warranty. Call us on 1300 736 970 if you need to make a claim.
Is Seagate Rescue data recovery included?
No. For this generation of SkyHawk, Seagate offered Rescue Data Recovery Services as an optional 2-year plan, not as part of the drive.
What speed does it spin at?
Seagate describes it as a low-RPM drive and does not publish a spindle speed. Its product manual lists 5.1 ms average latency, and the maximum sustained transfer rate is 180MB/s with a 64MB cache.
How much power does it use?
About 5.6 W while working, 4.0 W at idle and 0.5 W in standby or sleep. It needs 1.8 A from the 12 V rail at start-up, which the recorder supplies.
Do screws and cables come with it?
No. This listing is the bare drive. Use the SATA leads in your recorder and four 6-32 UNC screws. Ask us if your recorder did not come with them.
Can you fit it for me?
This listing is the drive on its own. When you buy a recorder or kit from us, choose the drive size in that product's options and it arrives fitted.
Supported by InFront Technologies.
Not sure which drive suits your recorder? Call 1300 736 970 or email [email protected]. The Seagate datasheet is on the Attachments tab.
Installation and safety
Low voltage only. The drive runs from the recorder's 5 V and 12 V supply. Always shut the recorder down and unplug it before opening it.
Handling. Seagate warns the drive is fragile and sensitive to static. Hold it by the edges, don't press on the top cover, and rest it on an antistatic surface until it is mounted.
Mounting. Use only 6-32 UNC screws, no deeper than 3.56 mm and no tighter than 6 inch-pounds, and leave 0.76 mm of clearance around the drive for cooling.
What it does not do. It is not an external drive and has no USB port. Formatting it in the recorder erases everything on it. Recording time depends on your cameras and settings, so we do not quote it.
Figures. From Seagate's SkyHawk datasheet DS1902.12 (June 2019) and SkyHawk product manual 100804836, ST2000VX008 column.
