HDMI Splitter 4 Port HDMI 2.0 HDR 4Kx2K 60Hz with EDID/Scaler down (HDCP 2.2)
AV-HDM2SP-60Hz-4
In Stock - Ready to Ship $ 165.00
inc-GST
- Max bandwidth: 450MHz
- Max baud rate: 13.5Gbps
- Input/Output TMDS signal: 0.5~1.5Volts p-p(TTL)
- Input/Output DDC signal: 5 Volts p-p (TTL)
- Input cable distance: ≤10m(1080P)/5M(4K) AWG24 HDMI standard cable
- Output cable distance: ≤10m(1080P)/5M(4K) AWG24 HDMI standard cable
- Max working current: 1000mA
- Power adapter format Input: AC (50HZ, 60HZ): 100V-240V
- Power adapter format Output: DC5V/2A
- Operating Temperature range: -0 to +40℃
- Storage Temperature range: -20 to +60℃
- Operating Humidity range: 5 to 85%RH (No Condensation)
- Storage Humidity range: 5 to 95%RH (No Condensation)
- Dimension (L x W x H): 139X64X22(mm)
- Weight: 220g
HDMI resolution:
- 4K@60Hz
- 4K@30Hz
- 3D
- 1080P
- 1080i
- 720p
- 576p
- 576i
- 480P
- 480i
Support video colour format:
- 24bit
- Deep colour 30bit
- 36bit
Support audio format:
- DTS-HD
- Dolby-TrueHD
- LPCM7.1
- DTS
- Dolby-AC3
- DSD
One HDMI 2.0 input signal split into four HDMI 2.0 sink devices
Supports HDR
Supports 4K*2K @60Hz resolution
Supports deep colour 24bit, 30bit, 36bit
Video Format Support:
- 4Kx2K/60Hz 10Bit YcbCr 4:2:0
- 4Kx2K/60Hz 12Bit YcbCr 4:2:0
- 4Kx2K/60Hz 8Bit YcbCr 4:4:4/YcbCR 4:2:0
- Note: It only supports the standard HDMI Source YcbCR4:4:4 Signal
Supports Blue-Ray 24/50/60fs/HD-DVD/xvYCC
Digital audio format:
- DTS-HD
- Dolby-TrueHD
- LPCM7.1
- DTS
- Dolby-AC3
- DSD
The HDMI Input Cable distance can be up to 10m and the HDMI Output Cable distance can be up to 10
- when transmitting the 1080P signal by using standard AWG24 HDMI Cable
The HDMI Input Cable distance can be up to 5m and the HDMI Output Cable distance can be up to 5m
- when transmitting the 4Kx2Knal by using standard AWG24 HDMI Cable
Support signal retiming
No loss of quality
Installs in minutes
Comes with a DC5V/2A power supply
Supports HDCP V2.2
