Bosch Solution 3000 Control Panel PCB Only - ICP-SOL3-P

Bosch Solution 3000 Control Panel PCB Only

ICP-SOL3-P

The Bosch Solution 3000 is a new generation alarm control panel for the Australian residential & commercial markets. Supporting up 16 fully programmable zones on the Solution 3000, this range of intrusion panels is suitable for any home, and even some commercial premises.

With support for up to four keypads on both panels and the ability to be split into two separate partitions on the Bosch Solution 3000, you have the flexibility of one security system that can act as two. The Bosch Solution 3000 control panel supports the Bosch Remote Security Control (RSC) app, enabling convenient system operation from an iPhone, iPad, or iPod Touch, including arming/disarming of the system and control of connected devices, such as lighting and A/C.

Power Requirements:

Primary: 250 VAC / 18 VAC at 1.3A supplied by TF008

Secondary: 12 VDC, 6.5Ah from rechargeable sealed lead/acid battery

Communications: CID, SIA, Email*, Domestic Dialing, CSV-IP, Push

Notification: *Requires B426-M IP Communications Module orMB450-M Universal Communications Module

Environmental Considerations

Temperature: 0o to +45oC

Relative Humidity: 10% to 95% non-condensing Enclosure

What's In the Box?:

• 1x Solution 3000 control panel
• 1x Solution 3000 Printed Quick Start Guide
• 1x Solution 3000 Printed User Guide
• 1x Update and release notes
• 1x Standard 610 telephone cable with adaptor
• 1x Battery leads Set
• 6x 3k3 resistors
• 6x 6k8 resistors
