ENSA Wall Mount PIR Sensor Motion Activated Switch
ENSA-PS1
The ENSA-PS1 is an intelligent sensor switch, designed for wall mounting. It features configurable ambient light sensing, passive infrared motion detection and on-time delay, so you may tailor light usage and energy consumption to your exact specifications.
Add three step energy saving to any light with sensor switches:
1) Daylight sensor: Activates motion sensor when lux levels fall below limit
2) Motion sensor: Detects movement, turns light on only when necessary
3) On-timer: Light-on duration is set only as long as is required
Product Features:
• Automatically activate and deactivate lighting for energy efficiency
• Adjustable sensors: Daylight (3~2000lx) / Motion (12m) / On-timer (10s~7min)
• 180° arc / 12m radius passive infrared detection
• Wall mount angle adjustable, IP65 rated for outdoor use
• 3 year warranty
- Dimensions
- 80 x 120 x 50mm
- Ingress Protection
- IP65
- Operating Environment
- -20 ~ 40°C /
- Input Voltage
- 220 ~ 240VAC 50Hz
- Daylight Sensing
- 3 ~ 2000 Lux
- Daylight Sensor
- Yes
- Max. Rated Load (Resistive/Inductive)
- 1200W / 300W
- Motion Detection Adjustment
- N/A
- Motion Detection Area
- 180° arc (12m radius)
- Motion Detection Speed
- 0.6 ~ 1.5m/s
- Motion Sensor Type
- Passive Infrared
- Mounting Type
- Wall
- On-timer Delay
- 10s ~ 7min
- Power Consumption (Sensing Mode)
- 0.5W
- Recommended Installation Height
- 1.8 ~ 2.5m
- Stand-by Dimming
- N/A
- Stand-by Period
- N/A
