Hikvision Ax Pro Wireless Outdoor Curtain PIR Detector - HIK-PDC10AM-EG2
- Active IR anti-masking
- Long range with narrow-angle detection
- Easy installation design
- Fully remote configurable through the Hik-Connect app
- Easily replaceable battery with PCB protection
- Frequency hopping
Hikvision Ax Pro Wireless Outdoor Curtain PIR Detector
HIK-PDC10AM-EG2
The Hikvision HIK-PDC10AM-EG2 outdoor curtain PIR detector has two-way wireless communication featuring motion detection, tamper protection, low battery, and RF supervision. It has a solid curtain coverage up to 10m long by 5m high. It is suitable for perimeter protection by setting up a detection curtain along walls or windows. It has a 12kg, wall-mounted pet immunity, active IR anti-masking, and is fully remote configurable through the Hik-Connect app.
N.B. The Axiom system is not compatible with the AX PRO system.
Product Features:
Slim design for window frame installation
IP65 weather resistance for outdoor application
Active IR anti-masking
Directional detection support
Multiple enrollment methods and easy installation
Frequency hopping against jamming for reliable transmission
Product Specifications:
Detection method: passive Infrared
Detection range: 10m wide, 5m high
Detection Angle: 5 degrees
Transmission range: 1km (open area)
Frequency: 433Mhz
Encryption: AES-128
Battery type: CR123A x 2
Battery life: 5 years
Size: 29.2mm x 134.4mm x 39.5mm
Weight: 120g
Ingress protection: IP65
