Securview VSCVI-8BIRP Professional Series 8.0MP WDR Fixed HDVCI Bullet (+Dual Motion Detection)

Securview VSCVI-8BIRP Professional Series 8.0MP VSCVI-8BIRP

Securview VSCVI-8BIRP Professional Series 8.0MP WDR Fixed HDVCI Bullet (+Dual Motion Detection)

Name: Securview VSCVI-8BIRP Professional Series 8.0MP WDR Fixed HDVCI Bullet (+Dual Motion Detection)
Brand: Securview Victory Series
SKU: VSCVI-8BIRP
Price: 127.13 AUD
Availability: InStock

Reference: VSCVI-8BIRP

In Stock - Ready to Ship

$ 127.13

inc-GST

Stream ~ UHD/4K/8.0MP @15fps
2.8mm fixed lens with 111° viewing angle
Dual pixel motion & infrared detection technology
Infrared illumination at up to 20m range
HDCVI / AHD / Composite switchable via DIP switch
Up to 700m video transmission over coaxial cable
True WDR (120dB) and 2D/3D noise reduction
IP67 rated weather resistance metal housing

Various Payment Types at Checkout.

All Payment Options are available at Checkout: Visa/MC/Amex, Zip, Afterpay, Paypal and Bank Dep

Securview Professional Series 8.0MP WDR Fixed HDVCI Bullet (+Dual Motion Detection)

VSCVI-8BIRP

Deliver accurate motion detection in any outdoor setting. The VSCVI-8BIRP combines pixel & PIR motion detection, eliminating false alarms and only activating when both motion & heat are detected at the same time.

Camera Features:

• Stream up to UHD/4K/8.0MP (3840 x 2160) at 15fps

• 2.8mm fixed lens with 111° viewing angle

• Dual pixel motion & infrared detection technology

• Infrared illumination at up to 20m range

• HDCVI / AHD / Composite switchable via DIP switch

• Up to 700m video transmission over coaxial cable

• True WDR (120dB) and 2D/3D noise reduction

• IP67 rated weather resistance metal housing

Backward compatible: HDCVI / AHD / TVI / Composite switchable via DIP switch. Analogue mode configuration via OSD using HDCVI DVR or tester.

Securview BIRP Series Datasheet (PDF)-1.jpg

Securview BIRP Series Datasheet (PDF)-2.jpg

Dimensions: 147 x 72 x 83mm
Housing: Aluminium (front cover) + Plastic (rear barrel)
Power input: 12VDC
Ingress Protection: IP67
Operating Environment: -10°C ~ +50°C/RH 95% (max)
Weight: 0.25kg
Power Consumption: < 5.3W
Video Output: 1 x HDCVI video output
Resolution: 8.0MP (3840 x 2160) to CIF (352 x 288)
Audio Input: N/A
Vandal Resistant: N/A
Category: HDCVI Surveillance
Series: Professional Series
Angle of View: 111°
Focus: Fixed / 1.8m Min Focus Distance
Frame Rate: 15fps (8.0MP) / 20fps (6.0MP) / 30fps (4.0MP and lower)
Effective Pixels: 3840 (H) x 2160 (V)
Image Sensor: 1/2" 8.0 Megapixel CMOS
Lens: 2.8mm F1.6 Fixed Lens
Minimum Illumination: 0.005 Lux at F1.6 (Colour) / 0 Lux IR Active
Alarm Interface: N/A
Camera Type: Bullet
Max. Resolution: 8.0 Megapixel
Lighting Compensation: BLC / HLC / WDR (120dB)
Transmission Distance: Rated for up to 700m via coaxial cable (performed in ideal test conditions)
Day/Night: Auto / Manual
Detect (25px/m): 84m
Electronic Shutter: 1/4s ~ 1/100,000s
Gain Control: AGC
Identify (250px/m): 8m
Infrared Range: 20m
Lens Type: Fixed
Mode Switching: OSD (via HDCVI recorder)
Modes Supported: HDCVI & Composite
Noise Reduction: 2D / 3D
Observe (63px/m): 34m
OSD Menu: Support
Recognise (125px/m): 17m
Signal Noise Ratio: >65db
Synchronisation: Internal
Tri-Axis Mounting: N/A
White Balance: Auto / Manual
