Dahua Waterproof Wall Mount White Dome Camera Bracket - DH-AC-PFB205W-E
DH-AC-PFB205W-E
In Stock - Ready to Ship
$ 22.00
inc-GST
The Dahua DH-AC-PFB205W is a durable water-proof wall mount bracket designed for selected Dahua turret and eyeball cameras. Built from strong aluminium alloy with a clean white finish, it provides a secure, professional mounting solution for indoor or outdoor camera installations. With a 2.0kg load capacity and compact design, it is ideal for tidy, reliable CCTV mounting.
- Water-proof aluminium alloy construction
- Suitable for selected Dahua turret & eyeball cameras
- Strong 2.0kg load-bearing wall mount design
Various Payment Types at Checkout.
All Payment Options are available at Checkout: Visa/MC/Amex, Zip, Afterpay, Paypal and Bank Dep
Dahua Waterproof Wall Mount Bracket
Model: DH-AC-PFB205W-E
Click image to enlarge
The Dahua DH-AC-PFB205W-E Waterproof Wall Mount Bracket is one of the most widely used CCTV mounting brackets in Australia. Designed specifically for Dahua turret (eyeball) cameras, it delivers a clean, secure and professional mounting solution for both residential and commercial installations.
Constructed from high-strength aluminium alloy, this bracket is built to withstand harsh outdoor environments while allowing internal cable routing to protect connections and eliminate exposed wiring.
Key Features
- Heavy-duty aluminium alloy construction
- Waterproof design for outdoor use
- Designed for Dahua turret / eyeball cameras
- Internal cable routing for professional finish
- 2.0kg load capacity
- Corrosion-resistant white finish
Why This Bracket Is So Popular
This bracket has become a go-to for installers because it fits a huge range of Dahua cameras, is easy to work with, and delivers a clean, sealed installation. It reduces call-backs, improves reliability, and gives a much more professional look compared to direct wall mounting.
Specifications
| Specification | Details |
|---|---|
| Material | Aluminium Alloy |
| Colour | White |
| Dimensions | 161.6 × 125.6 × 76.0 mm |
Extensive Camera Compatibility (AU Models)
This bracket suits Dahua turret (eyeball) cameras with the standard base pattern. This includes a wide range of current and legacy models used across Australia.
Current / Newer Models (ANZ Market):
- HDW3667EM-S-IL-ANZ
- HDW3867E-AS-IL-ANZ
- HDW3467 / HDW3567 / HDW3667 series
- HDW5442 / HDW5241 / HDW5541
- HDW5842 / HDW5849 / HDW5449
- HDW5249 / HDW5449T1 / HDW5849T1
Popular Installed Base (Australia):
- IPC-HDW3849 / 3549 / 3449 / 3249
- IPC-HDW2549 / 2449 / 2249
- IPC-HDW4231 / 4431 / 4631 / 4831
- IPC-HDW5231 / 5431 / 5831
- IPC-HDW1230 / 1431 / 1531 / 2231 / 2431 / 2831
HDCVI Turret Cameras:
- HAC-HDW1200 / 1400 / 1500 / 1800
- HAC-HDW2241 / 2501 / 2402 / 2601 / 2802
- HAC-HDW1509 / 1239 / 2249 LED series
Consumer Range:
- T1A / T2A / T3A / T4A / T5A turret cameras
Note: This bracket is not intended for bullet (HFW) cameras or large dome housings.
Installer Notes & Real-World Practices
In the field, installers often use this bracket beyond its official compatibility due to its flat mounting surface and versatility.
When holes do not line up:
- Use self-drilling (tech) screws to secure the camera base
- Pre-drill pilot holes where required for cleaner installs
- Ensure screws are positioned evenly to avoid camera tilt
Common installer techniques:
- Run cable through wall into bracket cavity for hidden wiring
- Use junction box inside wall for extra space
- Combine with conduit for exposed cable runs
This flexibility makes the PFB205W one of the most adaptable brackets in the industry.
IMPORTANT: Sealing & Waterproofing
Proper sealing of the bracket is critical in outdoor installations.
Best practice:
- Apply neutral cure silicone around the top and sides of the bracket
- Seal all cable entry points
- Ensure no gaps where water can track into the wall
What happens if you don’t seal it properly?
- Water ingress into wall cavity
- Corrosion of connectors and terminations
- Camera dropouts and intermittent faults
- Mould and structural damage over time
- Expensive call-backs and repairs
Even though the bracket is rated for outdoor use, the installation itself must be sealed correctly to maintain full weather protection.
