Dahua PFB204W: a white water-proof wall mount bracket that holds a Dahua eyeball camera out from the wall, with the cable running through the arm.
- ✓160 × 122 × 76 mm, 0.49 kg, carries 1 kg
- ✓Aluminium and SECC, white
- ✓4 × M4 camera pattern for Dahua eyeball bases
- ✓Listed by Dahua for EM-S, T and TLM series eyeballs
- ✓Screws, anchors and wrench included
- ✓−40 °C to +60 °C
Description

An eyeball camera, off the wall.
Dahua's water-proof wall arm with a four-screw pattern.
The Dahua PFB204W holds an eyeball camera out from a wall, with the camera hanging under the arm and its cable going through the centre hole. Dahua lists it for its EM-S eyeballs and several HDCVI eyeball ranges.
In one sentence: the Dahua DH-AC-PFB204W is a white aluminium and SECC water-proof wall mount bracket, 160 × 122 × 76 mm and 0.49 kg, rated to carry 1 kg, with a 4 × M4 camera pattern that Dahua lists for its EM-S and HDCVI eyeball cameras.
Bracket only. The camera is sold separately.
This listing is the PFB204W wall bracket with its fixings. Check your camera against Dahua's list in the Works with box below, or ask us before you order.
- PFB204W wall mount bracket
- 4 × M4 screws (camera to bracket)
- 4 × ST4 screws (bracket to wall)
- 4 × plastic anchors
- Wrench
- A compatible Dahua camera
- Network or coax cable to the camera
- Other fixings if the plastic anchors don't suit your wall
The camera hangs under the arm, the cable runs inside.
Screw the bracket to the wall with four screws, pass the camera cable through the centre hole, and fix the eyeball's base to the face of the arm with four M4 screws. The camera ends up clear of the wall, looking down and out over the area you want to watch.

Camera face
Four-screw pattern for eyeball bases.
Dahua's drawing shows 4 × M4 holes at 90° on 68.5 mm and 94 mm circles, plus a second 4 × M4 pattern at 85.1 × 32.2 mm. The centre hole and its side channel let the cable and connector pass up into the arm. Close-up from Dahua's product photo.

Arm and wall plate
160 mm tall, 76 mm out from the wall.
The arm is aluminium with an SECC steel part, finished in white, and weighs 0.49 kg. The wall end has four 5 mm holes at 76 × 26 mm spacing. Close-up from Dahua's product photo.
How it goes in
From bare wall to mounted camera.
01
Check the camera
Confirm your camera model is on Dahua's PFB204W list, and pick a spot with a clear view and a cable path back to the recorder.
02
Fix the bracket
Mark the four holes (76 × 26 mm), drill, and screw the bracket to the wall with the ST4 screws and anchors, or fixings that suit your wall.
03
Feed the cable
Bring the network or coax cable out of the wall behind the bracket and through the centre hole, leaving enough slack to connect the camera.
04
Mount the camera
Connect the camera, tuck the connectors into the arm, fix the camera base with the four M4 screws, then aim it.
At a glance
DH-AC-PFB204W
Show specs
Type
Water-proof wall mount bracket
Colour
White
Material
Aluminium and SECC
Size
160 × 122 × 76 mm (datasheet W × H × D)
Weight
0.49 kg
Load bearing
1 kg
Camera fixing
4 × M4 at 90° on 68.5 mm and 94 mm circles, and 4 × M4 at 85.1 × 32.2 mm (drawing)
Wall fixing
4 × 5 mm holes, 76 × 26 mm spacing (drawing)
Cable entry
Centre hole with side channel
Operating temperature
−40 °C to +60 °C
Humidity
Under 90% RH
In the box
Bracket, 4 × M4 screws, 4 × ST4 screws, 4 × plastic anchors, wrench
Weather rating
Called water-proof by Dahua; no IP rating published
Newer Dahua model
PFB2204W (marked New in Dahua's selection guide)

Dahua dimension drawing, measurements in mm [inch].
Works with
Dahua cameras listed for the PFB204W
From Dahua's own camera and kit datasheets and its Camera Accessories Selection guide (Oceania, December 2025). If your model is not here, confirm fit with us before you order.
Show all listed cameras
IPC-HDW3867EM-S-IL
Camera datasheet lists PFB204W as the wall mount
Dahua ACU8867 and ACU4867 D kits (eyeball versions)
Kit datasheets list PFB204W
Dahua K8044T-67, K8084T-67, K8086T-67, K8088T-67, K81610T-67, K81616T-67 kits
Kit datasheets list PFB204W
IPC-HDW3466EMP-S, IPC-HDW3666EMP-S, IPC-HDW3866EMP-S
Selection guide, recommended
IPC-HDW3467EM-S, IPC-HDW3667EM-S, IPC-HDW3867EM-S
Selection guide, recommended
IPC-HDW2541EMP-S, IPC-HDW2549EMP-S
Selection guide, recommended
HAC-HDW1200EM-A-S6, HAC-HDW1200EM-S6
Selection guide, recommended
HAC-HDW1801T-A-S2, HAC-HDW1801T-S2, HAC-HDW2802T-A
Selection guide, recommended
HAC-HDW T series LED and IL eyeballs (1809T, 1801T-IL, 1509T, 1500T-IL, 1239T, 1209T-IL, 1200T-IL, 2509T, 2249T)
Selection guide, recommended
HAC-HDW TLM series eyeballs (1801TLM, 1800TLM, 1500TLM, 1231TLM, 1200TLM, 2802TLM, 2501TLM, 2241TLM, 1500TLM-POC, 1200TLM-POC)
Selection guide, recommended
HAC-HDW TLM IL and LED eyeballs (1809TLM-A-LED, 1801TLM-IL, 1209TLM-IL, 1500TLM-IL, 1200TLM-IL, 2509TLM-A-LED, 2249TLM-A-LED)
Selection guide, recommended
HAC-HDW1800M
Selection guide, recommended
IPC-HDBW3466F-AS
Selection guide, recommended
Pair it with
What goes with it
Camera
Dahua IPC-HDW3867EM-S-IL eyeball
Its Dahua datasheet names the PFB204W as its wall mount. Other listed eyeballs are in the Works with box.
Pole
DH-AC-PFA152-E pole mount
For a post or pole from 80 to 150 mm. Dahua's selection guide shows the PFB204W going on the PFA152-E, and its 76 mm M4 pattern lines up with this bracket's wall holes.
Black finish
DH-AC-PFB204W-B
The same bracket in black, for black Dahua eyeballs.
Where it is used
Where a wall arm does the job.
Home eaves and walls
Hold an eyeball out from brick or cladding so it looks along the house and down the driveway.
Shopfronts
Mount an eyeball beside the entry where there is no ceiling or soffit to fix to.
Warehouses
Fix cameras to walls and columns to watch roller doors, racking aisles and loading docks.
Car parks and walkways
Wall-mounted cameras over parking bays, ramps and paths.
Offices and schools
Corridors, stairwells and reception areas where the camera needs to stand off the wall.
Posts and poles
With the PFA152-E pole mount behind it, the same arm goes on a post from 80 to 150 mm.
PFB204W or PFB203W
| PFB204W (this bracket) | PFB203W | |
|---|---|---|
| Camera fixing | 4 × M4 at 90° (68.5 and 94 mm circles) | 3 × M4 at 120° (84, 98 and 110 mm circles) |
| Suits | Dahua eyeballs such as the EM-S series, and the HDBW3466F-AS | Dahua domes, turrets and eyeballs on its list |
| Size | 160 × 122 × 76 mm | 160 × 122 × 76 mm |
| Weight | 0.49 kg | 0.5 kg |
| Load bearing | 1 kg | 1 kg |
| Datasheet name | Water-proof wall mount bracket | Wall mount bracket |
| Screws in the box | 4 × M4, 4 × ST4, 4 anchors | 3 × M4, 4 × ST4, 4 anchors |
| Newer Dahua model | PFB2204W | PFB2203W |
Figures from Dahua's PFB204W and PFB203W datasheets and its Camera Accessories Selection guide (Oceania, December 2025).
Common questions
Which cameras fit the PFB204W?
Dahua lists it for its EM-S eyeballs such as the IPC-HDW3867EM-S-IL, HDW3667EM-S and HDW3466EMP-S, many HDCVI eyeballs (T, TLM and EM series) and the IPC-HDBW3466F-AS. The full list is in the Works with box on this page.
Is a camera included?
No. This listing is the bracket with 4 M4 screws, 4 ST4 screws, 4 plastic anchors and a wrench. The camera is sold separately.
How much weight will it hold?
1 kg, according to Dahua's datasheet. Check your camera's weight on its own datasheet before you mount it.
How big is it?
160 × 122 × 76 mm and 0.49 kg. The camera face sits 76 mm out from the wall.
Is it waterproof?
Dahua calls the PFB204W a water-proof wall mount bracket, but its datasheet gives no IP rating. Keep the cable joins inside the arm and seal the wall entry.
Where does the cable go?
Through the centre hole on the camera face and up into the arm, then out of the wall behind the bracket. The side channel lets a connector pass through.
What screws hold the camera on?
Four M4 screws, supplied. Dahua's drawing shows four-hole patterns at 90° on 68.5 mm and 94 mm circles, plus a 4 × M4 pattern at 85.1 × 32.2 mm.
How is it fixed to the wall?
Through four 5 mm holes at 76 × 26 mm spacing, with the ST4 screws and plastic anchors supplied, or fixings that suit your wall.
Can I put it on a pole?
Yes, with a pole mount behind it. Dahua's selection guide shows the PFB204W on the PFA152-E pole mount (80 to 150 mm poles) and on its PFA156.
What temperatures can it handle?
Dahua rates it for −40 °C to +60 °C and humidity under 90% RH.
What is the difference from the PFB203W?
The PFB204W has a four-screw camera pattern for Dahua eyeballs such as the EM-S series. The PFB203W has a three-screw pattern for domes, turrets and other eyeballs. Both are 160 × 122 × 76 mm and carry 1 kg.
Is there a newer version?
Dahua's 2025 selection guide marks the PFB2204W as the new model alongside the PFB204W. This listing is the PFB204W.
Supported by InFront Technologies.
Not sure which bracket suits your camera or wall? Call 1300 736 970 or email [email protected]. The Dahua datasheet is on the Attachments tab.
Installation and safety
Mechanical part only. The PFB204W holds the camera. It carries no power or data; follow the camera guide for its connections.
Load. Rated for 1 kg. Check the camera weight on its own datasheet before you mount it.
Working at height. Cameras usually go on eaves, high walls or posts. Use a stable ladder or platform and fixings that suit the surface.
Cabling. Concealed data cabling to the camera is customer cabling under AS/CA S009 and needs an ACMA-registered cabler. A new power point needs a licensed electrician.
What it does not do. Dahua publishes no IP rating for this bracket, and it is not a junction box: there is no space for spare cable or connectors beyond what fits in the arm.
Figures. From Dahua's PFB204W datasheet (Rev 001.001), its camera and kit datasheets and its Camera Accessories Selection guide (Oceania, December 2025).
