• 8 × IVSEC NC340XB 12MP turret cameras
• IVSEC NR308XD 8-channel PoE recorder
• Recorder power supply, USB mouse and HDD screws
• The hard drive, only if you choose a drive option
• Camera installation templates, mounting screws and plugs
• Printed quick guides

• One Cat5e or Cat6 cable per camera, up to 100 m each
• A TV or monitor with HDMI or VGA, and an HDMI or VGA cable
• A surveillance hard drive, if you chose the no-drive option
• A network cable from the recorder to your router, for the phone app

01

Fit the drive

Fit the drive option, or your own 3.5-inch SATA surveillance drive, in the recorder with the supplied screws if it isn't already installed.

02

Run one cable per camera

Cat5e or Cat6 from each camera back to a PoE port on the recorder, up to 100 m per run. The recorder powers the cameras.

03

Mount and aim the cameras

Mark the holes with the installation template, fix each turret with the supplied screws and plugs, then angle the ball to frame the view.

04

Finish in the wizard and app

Connect a TV and your router, set the password in the startup wizard, scan the recorder's QR code with the IVSEC app, then set AI detection.

Storage

A drive option

Choose a 2TB, 6TB, 8TB, 10TB, 12TB or 14TB drive above so the kit records out of the box. Bigger drives keep footage for longer before it is overwritten.

Cabling

Cat6 cable

Eight runs of network cable, one per camera, each up to 100 m. Ask us for the lengths you need.

Security

A lockable cabinet

Keep the recorder out of reach so a thief can't take the footage with it. Ask us about the 24SECCAB security cabinet.

Power

A UPS

Keeps the recorder and cameras running through short power cuts and protects the drive from sudden shutdowns.

Large homes and acreage

Every door, driveway, shed and fence line on one recorder, with alerts only for people and vehicles.

Warehouses

Aisles, loading docks and roller doors, where 12MP detail helps you read what happened.

Retail stores

Entries, counters and stockrooms, with heat map and queue length on each camera.

Offices and clinics

Reception, corridors, entries and car park, viewed from a PC or the phone app.

Schools and community buildings

Entrances, halls and grounds covered from one recorder.

Car parks and yards

Vehicles and gates, with line crossing and intrusion alerts after hours.

What is in this kit?

Eight IVSEC NC340XB 12MP turret cameras and an IVSEC NR308XD 8-channel PoE recorder with its power supply, USB mouse and HDD screws, plus mounting screws, plugs and templates for the cameras. A hard drive is included only if you choose a drive option.

Does it come with a hard drive?

Not by default. The default option is no drive; choose a 2TB, 6TB, 8TB, 10TB, 12TB or 14TB drive option above, or fit your own 3.5-inch SATA surveillance drive. The recorder needs a drive to record.

Are network cables included?

No. You need one Cat5e or Cat6 cable from each camera to the recorder, up to 100 m per run. We can supply cable in the lengths you need.

Can I add more cameras later?

Not to this recorder. It has eight channels and all eight are used by the kit. For more cameras, look at the 14-camera kit on a 16-channel recorder.

Do the cameras need a power point each?

No. The recorder powers each camera through its network cable (PoE). Each camera draws under 7 W and can also run from a 12 V DC supply.

How far do the cameras see at night?

Up to 30 m with the built-in smart infrared, in black and white. Day and night switching is automatic.

Do the cameras record sound?

Yes. Each NC340XB has a built-in microphone. It has no speaker, so there is no talk-back. Check your state's surveillance laws before recording sound.

Do the cameras have strobe lights or a siren?

No. The NC340XB is an infrared camera without deterrent lights or a siren. IVSEC's NC340ADXB is the same size with strobes, white light and a speaker.

Which AI detections does it have?

Human and vehicle detection, face detection, perimeter intrusion, line crossing, stationary object, crossing counting, crowd density, queue length and heat map, set per camera.

Are the cameras weatherproof?

Yes. IVSEC's spec table rates the NC340XB IP67 (its overview text says IP66), vandal resistant, from −30 °C to 55 °C. The recorder is for indoor use.

Can the cameras record without the recorder?

Yes. Each camera has a microSD card slot, so it can keep its own copy of footage. The card is not included.

What warranty does the kit have?

IVSEC gives the cameras a 3-year warranty and the recorder 2 years on parts. InFront Technologies handles warranty and support in Australia on 1300 736 970.
