VIP Vision Power Over Ethernet Extender for VSPOE-EX

VIP Vision Power Over Ethernet Extender for Midspans - VSPOE-EX

VSPOE-EX
In Stock - Ready to Ship
$ 40.00
inc-GST
  • Active extender provides PoE to up to 3 IP surveillance cameras*
  • IEEE 802.3af/at standard for IP camera PoE power supply
  • Supports Ethernet data exchange
  • Junction box or DIN rail mounting



VIP Vision Power Over Ethernet Extender for Midspans



VSPOE-EX



The VSPOE-EX is an extender for the VSPOE-MS 60W PoE Midspan. It enables the cascading of PoE to up to three IP cameras, up to a maximum distance of 300m from the network switch. Hi-PoE ports from capable PoE switches can be used in place of the VSPOE-MS midspan.



Product Features:



• 1 x 10/100 Base-T PoE receiver port

• 1 x 10/100 Base-T PoE supply port for following VSPOE-EX extender

• 1 x 10/100 Base-T PoE supply for IP camera / device

• Active extender provides PoE to up to 3 IP surveillance cameras*

• IEEE 802.3af/at standard for IP camera PoE power supply

• Supports Ethernet data exchange

• Junction box or DIN rail mounting

*Device power consumption must be ≤8W



Dimensions
79 x 52 x 23mm
Operating Environment
-30° ~ 65°C / 10 ~ 90% RH (max.)
Weight
0.06kg
Mounting Options
Desktop / DIN Rail
Indicators
Power indicator / PoE status indicator
PoE Protocol
PoE (IEEE802.3af) / PoE+ (IEEE802.3at)
Exchange Mode
N/A
Lightning Protection
N/A
Ethernet Ports
3 x 10/100 Base-T (receiver port / extender port / device port)
PoE Power Supply
Cascades from midspan
