Dahua 5MP Motorised Zoom Eyeball Camera 2.7~13.5mm HDCVI Starlight Pro - DH-HAC-HDW2501TP-Z-A-DP-27135-S2
Dahua DH-HAC-HDW2501TP-Z-A-DP-27135-S2: a 5MP Starlight HDCVI eyeball with a motorised 2.7–13.5 mm auto-focus lens and built-in mic, for coax systems.
- ✓5MP at 25 fps on HDCVI; AHD, TVI and CVBS by switch
- ✓Motorised 2.7–13.5 mm F1.6 lens, auto focus
- ✓Starlight, 120 dB WDR, Smart IR up to 60 m
- ✓Built-in mic, audio over coax
- ✓IP67 metal housing, 24 VAC or 12 VDC
Description

Zoom from the recorder, not a ladder.
5MP HDCVI with a 2.7–13.5 mm motorised lens.
A 5MP Starlight eyeball for coax systems, with a motorised, auto-focus 2.7–13.5 mm lens, Smart IR up to 60 m and a built-in mic. The -DP version runs on 24 VAC or 12 VDC.
In one sentence: the DH-HAC-HDW2501TP-Z-A-DP-27135-S2 is a Dahua Pro Series 5MP Starlight HDCVI eyeball with a motorised 2.7–13.5 mm F1.6 auto-focus lens, 60 m Smart IR, 120 dB WDR, a built-in microphone, an IP67 metal housing and 24 VAC or 12 VDC power.
Analogue HD camera only. It needs an HDCVI recorder.
This listing is one white HDCVI eyeball. It does not connect to a network or an NVR: it plugs into a Dahua XVR (or another analogue HD recorder) over coax or UTP with baluns, and needs a 12 VDC or 24 VAC supply. For 5MP 16:9, Dahua says the XVR firmware must be V4.001.0000001.0.R.200908 or later.
- DH-HAC-HDW2501TP-Z-A-DP-27135-S2 eyeball camera
- A Dahua HDCVI recorder (XVR) with current firmware
- Coax (or UTP with passive baluns) to the camera
- A 12 VDC or 24 VAC supply, about 10 W per camera
Frame it once it is up.
The motorised lens goes from 113° wide to 31.4° zoomed and focuses itself. HDCVI carries video, audio and control on one coax cable, so the view can be adjusted from a recorder that supports it after the camera is mounted.

Front
5MP, wide or zoomed.
2880 × 1620 at 25 fps on HDCVI. At 2.7 mm it covers 113° across; at 13.5 mm it detects a person out to 210 m and identifies to 21 m (DORI).

Lens and IR
Starlight, then Smart IR to 60 m.
Colour down to 0.001 lux at F1.6. When it gets darker, 2 IR LEDs reach up to 60 m and Smart IR stops close subjects washing out. 120 dB true WDR, defog and 4× digital zoom.
How it goes in
From old camera to 5MP zoom.
01
Check the recorder
Use a Dahua XVR that supports 5MP HDCVI, on firmware V4.001.0000001.0.R.200908 or later for 5MP 16:9.
02
Mount the camera
Fix the base to the wall or ceiling, then aim the eyeball roughly (tilt up to 78°).
03
Connect coax and power
Plug the BNC into the coax run (or a passive balun on UTP) and connect 12 VDC or 24 VAC.
04
Zoom and focus
Leave the DIP switch on CVI, add the channel, then set the zoom. The lens focuses itself.
At a glance
DH-HAC-HDW2501TP-Z-A-DP-27135-S2
Show specs
Resolution
5MP, 2880 × 1620 at 25 fps (HDCVI, PAL)
Video output
CVI, AHD, TVI or CVBS by DIP switch, one BNC
Other modes
AHD and TVI 4MP at 25 fps; CVBS 960H
Lens
Motorised 2.7–13.5 mm, F1.6, auto focus
Field of view
113° to 31.4° horizontal, 138° to 36° diagonal
DORI (detect)
64 m at 2.7 mm; 210 m at 13.5 mm
Image sensor
1/2.7" CMOS
Low light
Starlight, 0.001 lux at F1.6; 0 lux with IR on
IR
Smart IR up to 60 m, 2 LEDs
WDR and image
120 dB true WDR, BLC, HLC, 3D NR, defog, 4× digital zoom
Audio
One built-in mic, audio sent over the coax
Power
24 VAC ±25% or 12 VDC ±10%, up to 9.5 W (12 VDC, IR on)
Protection
IP67
Housing
Metal throughout
Size and weight
Ø122 × 104.8 mm, 0.63 kg
Adjustment
Pan 0–360°, tilt 0–78°, rotate 0–360°
Operating range
−30 °C to +60 °C, humidity under 95%
Recorder firmware
Dahua XVR V4.001.0000001.0.R.200908 or later for 5MP 16:9
Warranty
Ask us

Ø122 × 104.8 mm. Three Ø4.5 mm holes on a Ø84 mm circle. Units mm (inch).
Pair it with
What this camera does not include
Recorder
A Dahua HDCVI recorder (XVR)
Records 5MP over coax and takes the audio from the built-in mic on the same cable.
Power
A 12 VDC or 24 VAC supply
Allow about 10 W per camera with the IR on.
Cabling
Coax, or UTP with baluns
Reuse existing coax, or run UTP with passive HDCVI baluns such as Dahua's PFM800-4K.
Mounting
A junction box
Dahua lists the PFA137 junction box for this camera, to hide the cable tail and connectors.
Where it is used
Where a motorised HDCVI eyeball fits.
Upgrading old analogue systems
Replace tired cameras on the same coax without re-cabling.
Driveways and gates
Zoom in on the gate or out across the yard, without a ladder.
Car parks
120 dB WDR for headlights at night and bright exits in the day.
Warehouses and yards
Long coax runs to the recorder, with IR to 60 m.
Shopfronts
Frame the door or the street after it is mounted.
Farms and sheds
A tighter view on a distant gate or shed door.
Wide or zoomed
| At 2.7 mm (wide) | At 13.5 mm (zoomed) | |
|---|---|---|
| Horizontal view | 113° | 31.4° |
| Detect (DORI) | 64 m | 210 m |
| Observe (DORI) | 25.6 m | 84 m |
| Recognise (DORI) | 12.8 m | 42 m |
| Identify (DORI) | 6.4 m | 21 m |
Both ends of the same lens, from Dahua's DH-HAC-HDW2501T-Z-A-DP datasheet (2501-S2 series). Everything else is the same.
Common questions
Will it work with my recorder?
It needs an HDCVI-capable recorder (a Dahua XVR) for full 5MP. A DIP switch also sets the output to AHD, TVI or CVBS for other analogue HD recorders, but those modes run at 4MP or 960H. It is not an IP camera and will not connect to an NVR.
Is it a dome, an eyeball or a bullet?
Dahua calls it an IR eyeball: a ball in a cradle under a fixed top cover, which you turn to aim. It is not a vandal dome with a clear bubble.
Is a recorder included?
No. This listing is the camera only. It needs an HDCVI or analogue HD recorder and a 12 VDC or 24 VAC supply.
How is it powered?
From 24 VAC (±25%) or 12 VDC (±10%), drawing up to 9.5 W on 12 VDC with the IR on. It does not take PoE.
How far does it see at night?
Smart IR reaches up to 60 m. In colour it works down to 0.001 lux at F1.6, and with the IR on it records at 0 lux.
How does the zoom work?
The 2.7–13.5 mm lens is motorised and focuses itself. HDCVI carries control signals over the coax, so the view can be adjusted from a recorder that supports it.
Does it record sound?
Yes. It has one built-in microphone, and the audio travels to the recorder over the same coax as the video.
How far can the cable run?
Dahua quotes up to 700 m for 5MP over coax and up to 300 m over UTP with baluns, from its own lab tests. Real runs depend on the cable quality.
Can it be mounted outside?
Yes. It is rated IP67 with a metal housing and runs from −30 °C to +60 °C.
Does it have AI detection?
No. Detection, recording and alerts are done by the recorder. The camera supplies the 5MP picture and audio.
What warranty does it have?
Ask us for the warranty term on this camera: call 1300 736 970 or email [email protected]. Claims are handled in Australia through InFront Technologies.
Who can install it?
It is a low-voltage camera on coax. Any new 230 V power point for the camera supply must be installed by a licensed electrician.
Supported by InFront Technologies.
Help matching the camera to your recorder: call 1300 736 970 or email [email protected]. The datasheet is on the Attachments tab.
Installation and safety
Low-voltage camera. 24 VAC or 12 VDC, up to 9.5 W. There is no mains connection on the camera. A new power point for the supply needs a licensed electrician.
Cabling. Coax or UTP from the camera to the recorder. Keep runs away from mains cable.
Audio. Recording conversations is covered by state and territory surveillance laws. Check them, and use signage, before you record sound.
What it does not do. Not an IP camera: no network port, no PoE, no NVR support, no microSD and no built-in AI. No speaker.
Figures. From Dahua's DH-HAC-HDW2501T-Z-A-DP datasheet (2501-S2 series, Rev 002) on the Dahua Australia website.
