Dahua DH-HAC-HDW2501TMQP-A-0280B-S2: a 5MP Starlight HDCVI quick-to-install eyeball with a fixed 2.8 mm lens and built-in mic, for upgrading coax systems.
- ✓5MP at 25 fps on HDCVI; AHD, TVI and CVBS by switch
- ✓Fixed 2.8 mm F1.6 lens, 111° across
- ✓Starlight, 120 dB WDR, Smart IR up to 60 m
- ✓Built-in mic, audio over coax
- ✓IP67 metal housing, 12 VDC
Description

5MP over the coax you already have.
Starlight, 60 m IR and a built-in mic.
An analogue HD eyeball for upgrading an existing coax system: 5MP Starlight video, sound from the built-in mic and power-friendly 12 V, on a quick-to-install base.
In one sentence: the DH-HAC-HDW2501TMQP-A-0280B-S2 is a Dahua Pro Series 5MP Starlight HDCVI quick-to-install eyeball with a fixed 2.8 mm F1.6 lens, 60 m Smart IR, 120 dB WDR, a built-in microphone and an IP67 metal housing.
Analogue HD camera only. It needs an HDCVI recorder.
This listing is one white HDCVI camera with a 2.8 mm lens. It does not connect to a network or an NVR: it plugs into a Dahua XVR (or another analogue HD recorder) over coax or UTP with baluns, and needs a 12 VDC supply.
- DH-HAC-HDW2501TMQP-A-0280B-S2 eyeball camera
- A Dahua HDCVI recorder (XVR) for 5MP
- Coax (or UTP with passive baluns) to the camera
- A 12 VDC supply, about 6 W per camera
An upgrade without new cable.
HDCVI sends video, audio and control over one coax cable. Swap the old analogue camera, keep the cable, and get 5MP at 25 fps with Starlight colour in low light and audio from the built-in mic.

Front
5MP through a 2.8 mm lens.
2880 × 1620 at 25 fps on HDCVI. The 2.8 mm F1.6 lens covers 111° across and detects people out to 63.6 m (DORI).

Lens and IR
Starlight, then Smart IR to 60 m.
Colour down to 0.001 lux at F1.6. When it gets darker, two IR LEDs reach up to 60 m and Smart IR stops close subjects washing out. 120 dB true WDR handles bright doorways.
How it goes in
From old camera to 5MP.
01
Check the recorder
Use a Dahua XVR that supports 5MP HDCVI. Other analogue HD recorders work in AHD, TVI or CVBS mode at lower resolution.
02
Fix the quick-to-install base
Screw the base to the ceiling or wall, then turn and tilt the eyeball (up to 78°) to frame the scene.
03
Connect coax and power
Plug the BNC into the coax run (or a passive balun on UTP) and connect a 12 VDC supply.
04
Set the output and view
Leave the DIP switch on CVI for a Dahua XVR, then add the channel and adjust the picture from the recorder.
At a glance
DH-HAC-HDW2501TMQP-A-0280B-S2
Show specs
Resolution
5MP, 2880 × 1620 at 25 fps (HDCVI, PAL)
Video output
CVI, AHD, TVI or CVBS by DIP switch, one BNC
Other modes
AHD and TVI 4MP at 25 fps; CVBS 960H
Lens
Fixed 2.8 mm, F1.6
Field of view
111° horizontal, 58° vertical, 132° diagonal
DORI
Detect 63.6 m, observe 25.4 m, recognise 12.7 m, identify 6.4 m
Image sensor
1/2.7" CMOS
Low light
Starlight, 0.001 lux at F1.6; 0 lux with IR on
IR
Smart IR up to 60 m, 2 LEDs
WDR and image
120 dB true WDR, BLC, HLC, 2D/3D NR
Audio
One built-in mic, audio sent over the coax
Power
12 VDC ±30%, up to 5.9 W with IR on
Protection
IP67
Housing
Metal dome and cover, plastic trim ring; quick-to-install base
Size and weight
Ø121.9 × 99.1 mm, 0.43 kg
Adjustment
Pan 0–360°, tilt 0–78°, rotate 0–360°
Operating range
−40 °C to +60 °C, humidity under 95%
Warranty
Ask us

Ø121.9 × 99.1 mm. Four 4.5 × 5.5 mm slots on a Ø84 mm circle. Units mm (inch).
Pair it with
What this camera does not include
Recorder
A Dahua HDCVI recorder (XVR)
Records 5MP over coax and takes the audio from the built-in mic on the same cable.
Power
A 12 VDC supply
Allow about 6 W per camera. Dahua lists the PFM321D 12 V 1 A adapter for this camera.
Cabling
Coax, or UTP with baluns
Reuse existing coax, or run UTP with passive HDCVI baluns such as Dahua's PFM800-4K.
Mounting
A junction box
Dahua lists the PFA137 junction box and PFB205W wall bracket for this camera.
Where it is used
Where a 5MP HDCVI eyeball fits.
Upgrading old analogue systems
Replace tired cameras on the same coax without re-cabling.
Shops and counters
A wide 111° view over the counter, with audio. Check the audio rules first.
Offices and receptions
A neat white eyeball for ceilings and entry walls.
Homes
Porches, garages and back yards on an existing DVR system.
Warehouses
Long coax runs to the recorder, with IR to 60 m in dark aisles.
Strata common areas
Lobbies, car park entries and bin rooms on the building XVR.
2.8 mm or 3.6 mm lens
| 2.8 mm lens (this listing) | 3.6 mm lens | |
|---|---|---|
| Horizontal view | 111° | 92° |
| Diagonal view | 132° | 109° |
| Detect (DORI) | 63.6 m | 80 m |
| Recognise (DORI) | 12.7 m | 16 m |
| Identify (DORI) | 6.4 m | 8 m |
| Close focus | 0.9 m | 1.6 m |
Both are columns of the same Dahua DH-HAC-HDW2501TMQ-A datasheet (2501-S2 series). This listing is the 2.8 mm version; everything else is the same.
Common questions
Will it work with my recorder?
It needs an HDCVI-capable recorder (a Dahua XVR) for full 5MP. A DIP switch also sets the output to AHD, TVI or CVBS for other analogue HD recorders, but those modes run at 4MP or 960H. It is not an IP camera and will not connect to an NVR.
Is it a dome or an eyeball?
Dahua calls it a quick-to-install IR eyeball: a ball in a cradle under a fixed top cover, which you turn to aim. It is not a vandal dome with a clear bubble.
Is a recorder included?
No. This listing is the camera only. It needs an HDCVI or analogue HD recorder and a 12 VDC supply.
How is it powered?
From a 12 VDC supply (±30% tolerance), drawing up to 5.9 W with the IR on. It does not take PoE.
How far does it see at night?
Smart IR reaches up to 60 m. In colour it works down to 0.001 lux at F1.6, and with the IR on it records at 0 lux.
Does it record sound?
Yes. It has one built-in microphone, and the audio travels to the recorder over the same coax as the video.
How far can the cable run?
Dahua quotes up to 700 m for 5MP over coax and up to 300 m over UTP with baluns, from its own lab tests. Real runs depend on the cable quality.
What does the 2.8 mm lens cover?
111° across and 58° up and down. It detects a person out to 63.6 m and identifies to 6.4 m (DORI).
Can it be mounted outside?
Yes. It is rated IP67 and runs from −40 °C to +60 °C.
Does it have AI detection?
No. Detection, recording and alerts are done by the recorder. The camera supplies the 5MP picture and audio.
What warranty does it have?
Ask us for the warranty term on this camera: call 1300 736 970 or email [email protected]. Claims are handled in Australia through InFront Technologies.
Who can install it?
It is a low-voltage camera on coax. Any new 230 V power point for the camera supply must be installed by a licensed electrician.
Supported by InFront Technologies.
Help matching the camera to your recorder: call 1300 736 970 or email [email protected]. The datasheet is on the Attachments tab.
Installation and safety
Low-voltage camera. 12 VDC only, up to 5.9 W. There is no mains connection on the camera. A new power point for the supply needs a licensed electrician.
Cabling. Coax or UTP from the camera to the recorder. Keep runs away from mains cable.
Audio. Recording conversations is covered by state and territory surveillance laws. Check them, and use signage, before you record sound.
What it does not do. Not an IP camera: no network port, no PoE, no NVR support, no microSD and no built-in AI. No speaker.
Figures. From Dahua's DH-HAC-HDW2501TMQ-A datasheet (2501-S2 series, 2.8 mm column) on the Dahua Australia website.
