IVSEC IVNC542ADX four-sensor 360 degree camera on its wall arm

IVSEC NC542ADX housing with four adjustable camera heads underneath

IVSEC NC542ADX wall arm (IV2491X, listed as included)

1 / 3

iVSEC 32MP Dome IP Camera 4-Directional 8MP Multisensor 25FPS IP66 IR - IVNC542ADX

Name: iVSEC 32MP Dome IP Camera 4-Directional 8MP Multisensor 25FPS IP66 IR - IVNC542ADX
Brand: IVSEC
SKU: IVNC542ADX
Price: 2925 AUD
Availability: InStock

SKU IVNC542ADX In Stock - Ready to Ship

$2,925.00 inc GST

IVSEC IVNC542ADX: a four-sensor 360° camera with four 8MP channels, each with its own motorised 2.8–12 mm lens, IR and white light to 35 m, and its wall arm included.

✓4 × 8MP channels, 3840 × 2160 each, 25 fps
✓4 adjustable 2.8–12 mm motorised lenses
✓4 × 1/1.8" sensors, IR and white light to 35 m
✓Gigabit network, ONVIF Profile S/G/T
✓IP67 and IK10, wall mount included
✓12 V DC, 24 V AC or PoE, under 43 W

IVSEC NC542ADX four-sensor 360 degree camera hanging from its wall arm, four lenses underneath

IVSEC · Multi-Sensor · 360°

Four 8MP cameras in one housing.
Aim each lens. Cover all four sides.

The IVSEC NC542ADX puts four 8MP (4K) sensors, each with its own motorised 2.8 to 12 mm lens, under one IP67, IK10 housing on a wall arm, so one mounting point can watch four directions or a full 360°.

In one sentence: the IVSEC IVNC542ADX is a four-sensor 360° IP camera with four 8MP (3840 × 2160) channels, four adjustable motorised 2.8–12 mm lenses, IR and white light to 35 m, gigabit networking and an IP67, IK10 housing with its wall arm.

Four camera channels in one unit. Recorder, cable and power are separate.

This listing is one multi-sensor camera. It shows up as four 8MP channels, so it needs four free channels on the recorder. It draws up to 43 W, so plan the power before you order.

In the box

NC542ADX multi-sensor camera
IV2491X wall mount (IVSEC lists it as included)
Printed quick user guide
Installation template
Mounting screws and plugs

You also need

An NVR or VMS with four free channels (ONVIF Profile S, G or T)
Cat5e or Cat6 cable to the camera
A 12 V DC or 24 V AC supply, or a PoE port that can deliver up to 43 W
IV2444X pendant mount or IV2488X pole mount bracket if it does not go on a wall

One mounting point instead of four cameras.

Hang it on a corner of the building or a pole and turn each of the four lenses to its own view: down two walls, across a car park and along a driveway. Each lens zooms from 112° wide to 48°, and each records its own 8MP stream.

IVSEC NC542ADX housing with IR and white light windows and four adjustable camera heads underneath

Four lenses

Four 1/1.8" sensors, each 2.8–12 mm.

Each channel records 3840 × 2160 from a 1/1.8" progressive CMOS sensor through its own motorised lens, 112° down to 48°. IR and white light in the housing reach 35 m, with automatic day and night switching.

The white wall arm of the IVSEC NC542ADX with its fixing plate

Mounting

Wall arm included, IP67 and IK10.

IVSEC lists the IV2491X wall mount as included. The camera is 195 × 300 × 300 mm and 7 kg, rated IP67 and IK10, from −30 °C to 55 °C. For a ceiling or pole, add the IV2444X pendant or IV2488X pole mount.

How it goes in

From the corner to four views.

Plan the mount

Pick a solid wall, corner or pole with a clear view in each direction. The camera weighs 7 kg; fix the wall arm with fixings rated for that load.

Run cable and power

Run Cat5e or Cat6 to the recorder or switch. Power it from 12 V DC, 24 V AC or a PoE port that can supply up to 43 W.

Add the four channels

Find it with IVSEC's Device Search / Config Tool, set a password, then add its four channels to an IVSEC NVR, the IVSEC app (QR code) or any ONVIF recorder.

Aim and zoom each lens

Turn each lens to its area, zoom it between 112° and 48°, then draw line crossing or intrusion zones for each view.

At a glance

IVNC542ADX

Show specs

Camera type

360° multi-sensor, four adjustable lenses

Resolution

4 × 8MP channels, 3840 × 2160 each

Frame rate

25 fps in the spec table (the overview says 30)

Image sensors

4 × 1/1.8" progressive CMOS

Lenses

4 × 2.8–12 mm motorised zoom, 112° to 48° horizontal

Night vision

IR and white light, up to 35 m, auto day/night

Video analytics

Motion, face recognition, pedestrian and vehicle detection, line crossing, intrusion, region entrance and exit, object detection, cross counting, heat map, crowd density, queue length, licence plate recognition

Audio

Input for an external microphone, audio out

Compression

H.265+, H.265, H.264+, H.264, MJPEG; 2 streams

Storage

microSD / SDHC card slot

Network

RJ45 10/100/1000 Mbps; ONVIF Profile S/G/T, HTTP API

Connectors

RJ45, DC power, analog video out, audio in and out, 4 alarm in or out

Power

PoE (IEEE 802.3at listed), 12 V DC or 24 V AC; under 43 W

Protection

IP67 weatherproof, IK10 vandal resistant

Size and weight

195 × 300 × 300 mm, 7 kg

Mounting

IV2491X wall mount included; IV2444X pendant and IV2488X pole mount optional

Operating range

−30 °C to 55 °C, humidity 95% or less

Warranty

3 years

Pair it with

What this camera does not include

Recorder

An NVR with four free channels

Each lens is its own 8MP channel. An IVSEC NVR or any ONVIF Profile S, G or T recorder works; count four channels for this camera.

Power

12 V DC, 24 V AC or high-power PoE

The camera draws up to 43 W, more than a standard 802.3at (PoE+) port delivers. Use a matching supply or ask us which PoE switch suits.

Mounting

IV2444X pendant or IV2488X pole mount

IVSEC's listed mounts for a ceiling or a pole. The IV2491X wall mount is already included.

Storage

A microSD card

Optional, for recording in the camera or as a backup when the network drops.

Where it is used

Where four views from one point pay off.

Building corners

Watch two walls and the area in front of each from one mounting point.

Car parks

Cover rows of bays in four directions from a single pole.

Intersections and driveways

See every approach to a junction or a shared entry.

Warehouse yards

Loading docks, gates and fences from the middle of the yard.

Schools and campuses

Quadrangles and walkways with fewer cable runs.

Retail precincts

Entrances, footpaths and parking around one building.

IVNC542ADX or IVNC540ADX

	IVNC542ADX (this camera)	IVNC540ADX
Channels	4 × 8MP	4 × 8MP
Image sensors	4 × 1/1.8" CMOS	4 × 1/2.7" CMOS
Lenses	2.8–12 mm, 112° to 48°	2.8–12 mm, 112° to 35°
Night vision	IR and white light, 35 m	IR and warm white, 30 m
Power	802.3at listed, 12 V DC, 24 V AC; under 43 W	802.3af listed, 12 V DC, 24 V AC; under 39 W
Weight	7 kg	4.6 kg

Figures from IVSEC's NC542ADX datasheet (updated 23 October 2026) and NC540ADX datasheet (updated 12 October 2026). Same 195 × 300 × 300 mm housing and wall arm; the NC542ADX has the larger 1/1.8" sensors for low light.

Common questions

Is it a 32MP camera?

Not as one picture. It has four separate 8MP cameras (3840 × 2160 each), and each lens records its own channel. Together that is 4 × 8MP, which is why it is sometimes sold as 32MP.

How many recorder channels does it use?

Four, one per lens. Make sure your NVR has four free channels and enough bandwidth for four 8MP streams.

Can each lens point a different way?

Yes. The four lenses are adjustable, so you can aim each one at its own area or set them to cover a full 360°.

Can I zoom each lens?

Yes. Each has a motorised 2.8–12 mm lens that zooms from 112° wide to 48°.

How is it powered?

From 12 V DC, 24 V AC or PoE, and it draws up to 43 W. IVSEC lists 802.3at PoE, but 43 W is more than a standard PoE+ port delivers, so ask us before relying on PoE.

What frame rate does it record?

The spec table lists 25 fps per channel; IVSEC's overview text says 30 fps. Plan on 25 fps.

How far does it see at night?

IVSEC rates the IR and white light to 35 m, with automatic day and night switching.

Is a wall mount included?

Yes. IVSEC lists the IV2491X wall mount as included. For a ceiling or pole, add the IV2444X pendant mount or IV2488X pole mount bracket.

Is a recorder included?

No. This listing is the camera only. It records to an IVSEC NVR, any ONVIF Profile S, G or T recorder, or a microSD card in the camera.

Does it record sound?

Only with an external microphone plugged into its audio input. There is no built-in microphone.

What is the difference from the NC540ADX?

Both have four 8MP channels with 2.8–12 mm lenses. The NC542ADX has larger 1/1.8" sensors, white light and IR to 35 m, and weighs 7 kg; the NC540ADX has 1/2.7" sensors, IR to 30 m and weighs 4.6 kg.

What warranty does it have?

Three years. InFront Technologies handles warranty and technical support in Australia on 1300 736 970.

Supported by InFront Technologies.

Help sizing the recorder, power and mount for a four-sensor camera: call 1300 736 970 or email [email protected]. The datasheet is on the Attachments tab.
