iVSEC 8MP 2-PACK 4K-UHD Panoramic AI 30FPS LED Smart Deterrence IP Camera - IVNC543ADX-2PK
IVSEC IVNC543ADX-2PK: two of the NC543ADX in one pack, each an 8MP panoramic turret camera with a 180° view, colour night vision, red and blue warning lights and two-way audio.
- ✓2 cameras in the pack
- ✓8MP, 3840 × 2160 at up to 30 fps
- ✓2.8 mm panoramic lens, 180° view
- ✓Warm white light, IR to 30 m
- ✓Red and blue warning lights, microphone and speaker
- ✓IP67 and IK10, PoE+ or 12 V DC
Description

180° in one 8MP picture.
A 2-pack of the IVSEC NC543ADX.
Two of the IVSEC NC543ADX in one pack, each an 8MP panoramic turret camera with a 180° view, colour night vision, red and blue warning lights and two-way audio.
In one sentence: the IVSEC IVNC543ADX-2PK is a pack of two IVNC543ADX cameras, each a wired 8MP (3840 × 2160) PoE panoramic turret camera with a 2.8 mm 180° lens at 30 fps, IR to 30 m, warm white and red and blue lights, a microphone and speaker, rated IP67 and IK10.
Two cameras. Network cables and recorder are not included.
This pack is two NC543ADX cameras. Each needs its own Cat5e or Cat6 cable back to a PoE port, and a recorder or VMS keeps the footage.
- 2 × NC543ADX camera
- Printed quick user guide (one set per camera)
- Installation template (one set per camera)
- Mounting screws and plugs (one set per camera)
- An IVSEC NVR, or another ONVIF Profile S, G or T recorder
- Cat5e or Cat6 cable for each camera
- Two PoE+ (802.3at) ports or a switch, or a 12 V DC supply
- IV2457X wall mount or a junction box if it does not go flat on an eave
One camera where you would have needed two.
The 180° lens covers a whole side of a house, a shopfront or a car park from one point, so there is no gap between two cameras to walk through. When someone crosses a line after hours the camera can switch on its lights, flash red and blue, and you can talk to them through the speaker.

Lights on
Warm white, red and blue.
The warm white light keeps night video in colour; IR reaches 30 m for black and white at a distance. Day, night, auto and scheduled modes are all available.

Lens
2.8 mm, 180°, 30 fps.
3840 × 2160 at up to 30 fps from a 1/2.7" progressive CMOS sensor, in one wide picture. The housing is 127 × 136 × 136 mm, rated IP67 and IK10, from −30 °C to 60 °C.
How it goes in
From the eave to a 180° view.
01
Pick the spot
Mount it in the middle of the area, facing out, so the 180° view reaches both ends. Use the installation template to mark the holes.
02
Run the cable
Run Cat5e or Cat6 to a PoE+ (802.3at) port on the recorder or a switch, or use a 12 V DC supply.
03
Add it to the recorder
Find it with IVSEC's Device Search / Config Tool, set a password, then add it to an IVSEC NVR, the IVSEC app (QR code) or any ONVIF recorder.
04
Set detection and lights
Draw line crossing or intrusion zones for people and vehicles, then choose when the white light and the red and blue lights switch on.
At a glance
IVNC543ADX-2PK
Show specs
In the pack
2 × IVNC543ADX, the same camera as the single listing
Camera type
Panoramic turret
Resolution
8MP, 3840 × 2160, up to 30 fps
Image sensor
1/2.7" progressive CMOS
Lens
2.8 mm fixed panoramic, 180°
Night vision
IR up to 30 m; warm white light for colour
Lights
IR, red and blue, warm white
Day/night modes
Day, night, auto, schedule
Audio
Built-in microphone and speaker
Video analytics
Motion, face recognition, pedestrian and vehicle detection, line crossing, intrusion, region entrance and exit, object detection, cross counting, heat map, crowd density, queue length, licence plate recognition
Compression
H.265+, H.265, H.264+, H.264, MJPEG; 3 streams
Storage
microSD / SDHC card slot
Network
RJ45 10/100/1000 Mbps; ONVIF Profile S/G/T
Power
PoE+ (IEEE 802.3at) or 12 V DC, under 14 W
Protection
IP67 weatherproof, IK10 vandal resistant
Size and weight
127 × 136 × 136 mm, 0.8 kg
Operating range
−30 °C to 60 °C, humidity 90% or less
Warranty
3 years
Pair it with
What this camera does not include
Recorder
An IVSEC NVR
Records around the clock. Any ONVIF Profile S, G or T recorder can also be used.
Power
A PoE+ port or switch
IVSEC lists 802.3at (PoE+) for this camera, or a 12 V DC supply. It draws under 14 W.
Mounting
IV2457X wall mount
IVSEC's 90° wall mount for this camera. The IV2422X, IV2433X and IV2480X boxes are also listed.
Storage
A microSD card
Optional, for recording in the camera or as a backup when the network drops.
Where it is used
Where a 180° camera fits.
Front of a house
Driveway, porch and front yard in one picture from the middle of the eave.
Shopfronts
The whole footpath and entry, with a voice warning after hours.
Car parks
A full row of bays without a blind spot between two cameras.
Backyards
Fence line to fence line from the back wall.
Warehouse walls
A long wall of roller doors from one mounting point.
Reception areas
Counter and waiting area in one view, with two-way audio.
IVNC543ADX-2PK or a single IVNC543ADX
| IVNC543ADX-2PK (this pack) | IVNC543ADX (single) | |
|---|---|---|
| Cameras | 2 | 1 |
| Camera model | NC543ADX | NC543ADX |
| Specifications | Identical | Identical |
| Cables and PoE ports needed | 2 | 1 |
The only difference is quantity: both listings are the same NC543ADX camera from the same IVSEC datasheet.
Common questions
How wide is the view?
180°. The 2.8 mm panoramic lens covers a whole side of a building in one 3840 × 2160 picture.
Does it show colour at night?
Yes, with the warm white light on. Without it, the IR gives black and white video to 30 m. You can choose day, night, auto or scheduled modes.
What do the red and blue lights do?
They flash as a warning when an alarm rule triggers, so an intruder knows the camera has seen them.
Can I talk through it?
Yes. IVSEC lists a built-in microphone and speaker, so you can listen and speak through the recorder or app. Check your state's laws before recording audio.
What is in the pack?
Two NC543ADX cameras, each with a printed quick user guide, installation template and mounting screws and plugs. Cables and a recorder are not included.
How is it powered?
From a PoE+ (802.3at) port or switch, or a 12 V DC supply. It draws under 14 W.
What frame rate does it record?
Up to 30 fps at 3840 × 2160 (8MP).
Which analytics does it have?
Motion, face recognition, pedestrian and vehicle detection, line crossing, intrusion, region entrance and exit, object detection, cross counting, heat map, crowd density, queue length and licence plate recognition.
Is it weatherproof?
Yes. It is rated IP67 for weather and IK10 for impact, and runs from −30 °C to 60 °C.
Which mount do I need for a wall?
IVSEC lists the IV2457X 90° wall mount, plus the IV2422X, IV2433X and IV2480X boxes, for this camera.
Should I choose the NC543ADX or the NC544ADX?
Both see 180°. The NC543ADX uses one sensor for a 3840 × 2160 picture at 30 fps; the NC544ADX uses two sensors for a wider 5120 × 1440 strip at 15 fps.
How is the 2-pack different from the single camera?
Only the quantity. Each camera in the pack is the same NC543ADX with the same specifications, mounting parts and 3-year warranty.
Supported by InFront Technologies.
Help placing a 180° camera or choosing the mount: call 1300 736 970 or email [email protected]. The datasheet is on the Attachments tab.
Installation and safety
Low-voltage camera. Runs from PoE+ or 12 V DC, under 14 W. There is no mains wiring. A new power point needs a licensed electrician.
Cabling. Concealed data cabling is customer cabling under AS/CA S009 and needs an ACMA-registered cabler.
Audio and privacy. Recording conversations and filming beyond your boundary are covered by state and territory surveillance laws. Use signage and check the rules before you switch on audio.
What it does not do. No zoom (fixed 2.8 mm lens), no Wi-Fi and no battery. IVSEC does not list a siren.
Figures. From IVSEC's NC543ADX datasheet, updated 23 October 2026.
