VIGI InSight 8MP Panoramic Bullet Camera 180° InSight-S385DPS
VIGI InSight 8MP Panoramic Bullet Camera 180° InSight-S385DPS
VIGI InSight 8MP Panoramic Bullet Camera 180° InSight-S385DPS
VIGI InSight 8MP Panoramic Bullet Camera 180° InSight-S385DPS
VIGI InSight 8MP Panoramic Bullet Camera 180° InSight-S385DPS

VIGI InSight 8MP Panoramic Bullet Camera 180° View, Colour Night Vision & AI Detection - InSight-S385DPS

InSight-S385DPS
In Stock - Ready to Ship
$ 698.00
inc-GST

or 4 interest-free payments of $174.50 with

  • 8MP ColourPro panoramic bullet
  • Weather / protection: IP67 · IK10
  • Max resolution: 5456×1520
  • See specifications for lens options
  • Standalone camera — NVR and mounts sold separately



TP-Link VIGI InSight S385DPS

8MP ColourPro panoramic bullet

VIGI InSight 8MP Panoramic Bullet Camera 180° View, Colour Night Vision & AI Detection - InSight-S385DPS

Overview

The InSight-S385DPS is a Dual-lens 180° panoramic 4K bullet with ColourPro, active deterrence, IP67 + IK10.

Standalone IP camera — NVR / PoE switch / mounts sold separately. Specs below match TP-Link Australia.

InSight-S385DPS build features
BUILD

8MP ColourPro panoramic bullet

Dual-lens 180° panoramic 4K bullet with ColourPro, active deterrence, IP67 + IK10. Official protection: IP67 · IK10.

InSight-S385DPS
PERFORMANCE

Resolution 5456×1520

Designed for Australian installs with PoE-friendly networking and VIGI / InSight management apps.

Key specs

SpecificationDetail
Max. resolution5456×1520
Focal length5 mm
Image sensorDual 1/1.79” Progressive Scan CMOS
ProtectionIP67 Weatherproof, IK10 Vandal-Proof
Power• 12V DC ± 5%, Max. 18W, 5.5 mm Coaxial Power Plug• PoE: 802.3at, Class 4, Max. 21W
Net weight1.12 kg

Full specifications are in the Specifications tab. Source: TP-Link Australia.

Recommended mounts

Official AU accessory matrix. Confirm your exact model before ordering.

  • VJB-305 — larger InSight junction box where listed
  • VMB-350 — pole bracket for 70–130 mm poles (bullet / PT)

Frequently asked questions

What weather / vandal rating does TP-Link publish?

TP-Link Australia lists IP67 · IK10 for this model.

Which junction box or pole mount do I need?

On the AU accessory matrix this camera maps to: VJB-305 — larger InSight junction box where listed; VMB-350 — pole bracket for 70–130 mm poles (bullet / PT).

Is this a kit?

No — this listing is the standalone camera. NVR, cable and mounts are sold separately unless the product title says Kit.

Need help matching this camera to an NVR or mount?
Infront Technologies stocks and supports TP-Link VIGI across Australia — call 1300 736 970 or email [email protected].

Install note. Use an ACMA-registered cabler for concealed customer cabling (AS/CA S009). Specs and imagery can change at TP-Link’s discretion — verify against the current AU product page before ordering.

Net Weight
1.12 kg
Ingress Protection
IP67
Vandal Resistance
IK10
Power
• 12V DC ± 5%, Max. 18W, 5.5 mm Coaxial Power Plug• PoE: 802.3at, Class 4, Max. 21W
Brand
TP-Link
Image Sensor
Dual 1/1.79” Progressive Scan CMOS
Lens
5 mm
Max. Resolution
5456×1520
Warranty
Australian Warranty via Infront Technologies
Product Family
VIGI InSight
Model
S385DPS
CategorySpecification
CAMERA
Image SensorDual 1/1.79” Progressive Scan CMOS
Shutter Speed1/3 to 1/10000 s
Slow ShutterYes
Minimum Illumination0.0005 Lux; 0 Lux with IR/White Light
Day/Night MechanismIR Cut Filter
Day/Night SwitchUnified/ Scheduled/ Auto
LENS
TypeFixed Focal Lens
Focal Length5 mm
ApertureDual F1.0
FOV• Horizontal FOV: 180°, Vertical FOV: 51°, Diagonal FOV: 180°
Lens MountM16
DORI Distance5mm:• D: 249 ft (76 m)• O: 95 ft (29 m)• R: 46 ft (14 m)• I: 23 ft (7 m)
ILLUMINATOR
IR LED• Quantity: 2• Range: 164 ft (50 m)†• Wavelength: 850 nm
White LED• Quantity: 2• Range: 164 ft (50 m)†
Illuminator On/Off ControlAuto/Scheduled/Always on/Always off
VIDEO
Max. Resolution5456×1520
Main Stream• Frame Rate：50Hz：1fps 5fps 10fps 15fps 20fps 25fps 60Hz：1fps 5fps 10fps 15fps 20fps 24fps • Resolution:5456×1520, 4096×1152, 2160×608Note: Enabling people counting or object attribute analysis limits the frame rate to 20fps.
Sub-Stream• Frame Rate：50Hz：1fps 5fps 10fps 15fps 20fps 25fps 60Hz：1fps 5fps 10fps 15fps 20fps 24fps • Resolution:2160×608, 1280×360Note: Enabling people counting or object attribute analysis limits the frame rate to 20fps.
Bit Rate ControlCBR, VBR
Video Compression• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 TypeHigh Profile
H.264+Main Stream Supported
H.265 TypeMain Profile
H.265+Main Stream Supported
Video Bit Rate• Main Stream: 256 Kbps to 8 Mbps• Sub-Stream: 64 Kbps to 1024 Kbps
INTERFACES
Network Interface1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm1 Alarm In, 1 Alarm OutRed-Blue Warning Lights
Reset ButtonYes
PowerDC Power Port
On-board StorageBuilt-In Memory Card Slot, Support MicroSD Card, up to 512 GB*
Built-in MicrophoneYes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in SpeakerYes
Audio1 Audio In, 1 Audio Out
GENERAL
Operating Temperature-30 °C to 60 °C (-22 °F to 140 °F)
Storage Temperature-40 °C to 60 °C (-40 °F to 140 °F)
Operating Humidity95% or Less (Non-Condensing)
Storage Humidity95% or Less (Non-Condensing)
Package Content• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
MaterialMetal
Net Weight1.12 kg
Power Supply• 12V DC ± 5%, Max. 18W, 5.5 mm Coaxial Power Plug• PoE: 802.3at, Class 4, Max. 21W
ProtectionIP67 Weatherproof, IK10 Vandal-Proof
Product Dimensions (L x W x H)10.5 × 4.6 × 3.5 in (266 × 116 × 90 mm)
CertificationsCE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF

InSight-S385DPS build features
