TP-Link VIGI Network Camera Junction Box - VJB-305
VJB-305
In Stock - Ready to Ship $ 49.00
inc-GST
or 4 interest-free payments of $12.25 with
- Larger aluminium alloy network camera junction box
- Indoor / outdoor wall or ceiling mounting
- Dimensions: 155.56 × 150 × 51 mm (6.1 × 5.9 × 2.0 in)
- Weight: 416 g · VIGI White
- For listed InSight models only (see description)
- Not a drop-in for VIGI C-series — use VJB-300 for those
TP-Link VIGI VJB-305
Larger junction box for listed InSight cameras.
Overview
Larger aluminium junction box — 155.56 × 150 × 51 mm, 416 g — for listed InSight models only. Not a C-series box.
ADD-ON ACCESSORY — INSIGHT MODELS ONLY
C355 / C385 / C455 / C485 / C540 use VJB-300. VJB-305 is only for the eight InSight models below.
In the box
- VIGI VJB-305 junction box
- Mounting accessories
- Waterproof accessories
What you also need (sold separately)
- Compatible InSight camera
- Cat 5e / Cat 6 Ethernet
- PoE NVR or PoE switch
SIZE
Bigger than VJB-300.
155.56 × 150 × 51 mm · 416 g. More room for cable slack. Waterproof accessories included; no published IP rating.
FIT
Eight InSight models.
S245ZI, S445ZI, S485PI, S345ZI, S345-4G, S385PI, S385DPS, LPR345Z — that is the AU list. Everything else is a different SKU.
POLE
Bullets often need VMB-350.
Listed InSight bullets also take VMB-350 on poles. Junction box ≠ pole bracket — order both when needed.
Install in four steps
- Confirm modelCheck your InSight SKU is on the eight-model list.
- Mount the baseTemplate, drill, fix the larger base for wall or ceiling.
- WaterproofFit waterproof cable attachments before hanging the camera.
- Fit cameraUse the QIG hole map, bolt on, close the cover.
Compatible camera models
From TP-Link Australia’s VIGI accessory matrix. Listed models and higher hardware versions are supported.
InSight
InSight LPR345Z · InSight S245ZI · InSight S345-4G · InSight S345ZI · InSight S385DPS · InSight S385PI · InSight S445ZI · InSight S485PI
Source: tp-link.com/au/vigi-accessories/product-list/ (VJB-305 filter).
Key specs — VJB-305
| Specification | Detail |
|---|---|
| Product type | VIGI Network Camera Junction Box |
| Model | VJB-305 |
| Material | Aluminium alloy |
| Appearance | VIGI White |
| Weather protection | Waterproof design (no published IP rating) |
| Mounting | Indoor / outdoor wall or ceiling |
| Product dimensions | 155.56 × 150 × 51 mm (6.1 × 5.9 × 2.0 in) |
| Weight | 416 g |
| Compatibility | InSight S245ZI, S445ZI, S485PI, S345ZI, S345-4G, S385PI, S385DPS, LPR345Z |
| Package contents | Junction box, mounting accessories, waterproof accessories |
| Warranty | Australian warranty via Infront Technologies |
Pair it with
- BULLET: InSight S345ZI / S345-4G / S385PI — Primary InSight bullets on the VJB-305 list.
- TURRET / DOME: InSight S445ZI / S485PI / S245ZI — Listed turret and dome bodies for this larger box.
- LPR: InSight LPR345Z — Licence-plate bullet on the same junction pattern.
- C-SERIES: Use VJB-300 instead — C355, C385, C455, C485, C540 — not VJB-305.
Frequently asked questions
Is this IP67?
No. Earlier marketplace copy claiming IP67 was incorrect. TP-Link does not publish an IP rating for VJB-305.
Same size as VJB-300?
No. VJB-305 is 155.56 × 150 × 51 mm; VJB-300 is ∅125 × 130.47 × 45.7 mm.
Will it fit VIGI C485?
No. C485 uses VJB-240 / VJB-300. VJB-305 is InSight-only on the AU matrix.
Do I still need a pole mount?
For round poles, yes — add VMB-350 for listed InSight bullets. VJB-305 alone is a wall/ceiling junction box.
Ordering an InSight on the VJB-305 list?
Infront Technologies stocks and supports TP-Link VIGI across Australia — call 1300 736 970 or email [email protected] for a compatibility check before you order.
Installation note. The VJB-305 is a passive mounting accessory. Confirm the wall or pole can support at least three times the combined camera + mount weight. Concealed customer cabling must be installed by an ACMA-registered cabler (AS/CA S009). Verify your camera against the current AU matrix before ordering.
- Dimensions
- 155.56 × 150 × 51 mm
- Weight
- 416 g
- Material
- Aluminium Alloy
- Colour
- VIGI White
- Brand
- TP-Link
- Mounting
- Indoor / outdoor wall or ceiling
- Package Contents
- Junction box, mounting accessories, waterproof accessories
- Warranty
- Australian Warranty via Infront Technologies
- Product Type
- Network Camera Junction Box
- Product Family
- VIGI Accessory
- Model
- VJB-305
- Compatibility
- InSight S245ZI, S445ZI, S485PI, S345ZI, S345-4G, S385PI, S385DPS, LPR345Z
